Frozen Fruits Vegetable Processing Machine Production Line1

Frozen Fruits Vegetable Processing Machine Production Line1 thumbnail-1
Frozen Fruits Vegetable Processing Machine Production Line1 thumbnail-2
Frozen Fruits Vegetable Processing Machine Production Line1 thumbnail-3
Frozen Fruits Vegetable Processing Machine Production Line1 thumbnail-4
Frozen Fruits Vegetable Processing Machine Production Line1 thumbnail-5
Frozen Fruits Vegetable Processing Machine Production Line1 thumbnail-6
Frozen Fruits Vegetable Processing Machine Production Line1 photo-1
Frozen Fruits Vegetable Processing Machine Production Line1 photo-2
Frozen Fruits Vegetable Processing Machine Production Line1 photo-3
Frozen Fruits Vegetable Processing Machine Production Line1 photo-4
Frozen Fruits Vegetable Processing Machine Production Line1 photo-5
Frozen Fruits Vegetable Processing Machine Production Line1 photo-6
US$ 10000.00 ≥1 Set
Key Specifications
Get Latest Price
core components:
Motor, Gearbox, Bearing, Engine, PLC
place of origin:
shanghai
weight:
1000 KG
Contact Supplier Request Quote Chat Now
Zhangjiagang Genyond Machine Co Ltd.
Gold Verified Supplier
1Yr
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
core components Motor, Gearbox, Bearing, Engine, PLC
place of origin shanghai
weight 1000 KG
warranty 1 Year

Introduction of frozen okra production line:

1. We offer turn key project of frozen okra production line from capacity to 50kg per hour to 2000kg per hour.

2. It is more convenient to operate, adjustable and low broken rate, reduces

labor time but raises output.

3, We have rich experience on frozen fruit and vegetable production line. Now our line has been installed in KSA, Algeria, tunis, Morocco,Zambia and so on.



No

Project

Contents

Remarks

1

Capacity

2000Kg/h

Fresh OKRA

2

Processing time

10-100min adjustable

Manual operation & frequency control

3

Feeding temperature

Room temperature



4

Width of conveyor belt

750mm/650mm/1300mm

Wire belt   /   food grade PVC belt   / quick-freezing machine belt

5

Blanching temperature

80-100°C adjustable

Using screw peel and blanching

6

blanching required steam

1.0 T/h

(0.4-0.7)Mpa

7

Air cooled

room temperature cooling & freezing cooling

8

gas consumption for fryer

25~35L/H

gas

9

Water consumption

Water supply first time around 20T

Sink water supply

10

Water consumption

About 5.0T/h

Mainly engaged in washing and peeling

11

Installed power

284Kw

380V/50HZ

12

Workshop space

50meters in length and 10meters in width

13

Number of operators

6-7 peoples



1. process

okra——de-stoner&cleaning——washing——inspecting——cutting——grading——blanching——conditioning——pre-cooling ——frozen——packing ——cold storage

2.Capacity (50kg per hour to 2000kg per hour for choosing)





Frozen Fruits Vegetable Processing Machine Production Line1





FAQ
1,What is the voltage/phase for this machine ?
380V 50Hz/three phase , also can made as the clients' request
2,What is the Mode of transportation ?
As client's request, shipping by sea or air
3,How long can we get the goods?
Depends on the different machine and differnte place would take different times
4,How long is the guarantee?
we promise guarantee as one year for non-human damage factor.
5,How should I do if meet some trouble while using?
we can supply English manual book and also take a video for showing how to resolve the problems or dispatch our worker to your factory.
6,What about Payment term?
T/T(Telegraphic Transfer )-30% as prepayment by T/T, after seen the copy of the B/L sent by fax,
the balance of 70% should be effected . Western Union ,L/C ,Trade Assurance,Etc.
7,What’s your MOQ
1 set
8, How can i contact with you ?
You can send inquiry to me .
Company Information

Advantages

Packaging & Shipping



PACKAGE

Standard export carton or wooden cases packing.

DELIVERY TIME:

7-20 days after confirming order,detail delivery date should be decided according to production season and order quantity.
