Fermention tank is widely used in dairy products,beverages,biological engineering,pharmaceutical,fine chemical industries,tank with interlayer,insulation,heating,cooling.
can according to customer inquired to customized .
Capcity: 5L-20000L
Pressure: 0.1Mpa-0.6Mpa
Rotate speed: 50-200/400rpm
Agitator type: Mechanical agitator
Material: Contacting parts is made by SS316,other parts is made by SS304
Surface finishes:
Inside surface Ra0.28μm - 0.4μm by mechanical polishing or electropolishing
Outside surface Ra0.6μm - 0.8μm by satin finishing
Feature:
1. Fermentors can be sterilized easily by sterilizable -in -place
2. Large 10.4" colourful simens touch screen simplifier entering set points and provides displays of parameter.
3. Advanced software to make it easy for operation and understanding.
4. Stainless steel vessel, piping and control cabinet has long life
5. Excellent stability and convenient to operate
6. Modular design provide system flexibility
7. Small footprint to minimize space requirement
8. Opening piping frame with plenty of space between valves and piping, make it easy for operation and maintenance
| Model | GY-196 |
| Working volume | 3-20000L |
| Filling volume | 65-75% |
| Material | Wetted parts are SS316L, and others are SS304. Vertical type with sight glass. |
| Surface finish |
Internal surface is 0.28-0.6μm by mechanical polishing, (passivation or electro-polish are optional) outside surface is 0.4-0.8μm by satin finish. |
| Pressure |
Working pressure inside vessel: 0.2mpa Design pressure inside vessel: 0.25mpa Working pressure inside jacket: 0.3mpa Design pressure inside jacket: 0.35mpa Pressure can be also designed according to client’s detail requirement. |
| Agitator |
1.Fermentor use SEW motor reducer mechanical agitator with two layer six blade impeller, one layer defamer and four baffles. chanical seal (single or double mechanical seal) 4.speed range: 50-400rpm (it depends on the size of the vessel) |
| Configuration of vesse |
1. Using alcohol flame inoculation 2.sterile sampling vale and bottom valve 3.PH, DO, temp. sensor on lower side, side glass, top with foam and level probe, and 12v sight glass with lamp, etc. |
| Construction |
Floor-type One fermentor vessel with one control system (Siemens PLC and HMI) |
| Operating panel | Chinese and English version |
1. The blanching machine is maily used for food processing. The water inside the blanching machine is hot water, and the heating method is hot temperature, so long-term use is more cost-effective. The blanching machine is completely mechanized during use and requires no labor. The material is fed into the blanching machine through the mesh belt/conveyor belt or manually. The equipment inside the blanching machine is controlled by frequency conversion, and the blanching time can be set according to different product processes.
2. The machine adopts SUS 304 plate mesh belt transmission. The mesh belt has the characteristics of high strength, small flexibility, no deformation, easy maintenance, etc. The whole machine suns in balance and low noise, which greatly improves the working efficiency. When the material is discharged, the belt is lifted to directly convey the material out of the equipment.
3. The heating source of the machine is natural gas heating, with automatic control steam inlet device and surface insulation. Minimize energy waste.
4. The transmission system of the machien adopts the speed reduction motor to make the conveyor belt transfer speed adjustable, and the blanching time can be adjusted freely.
5. Now the blanching equipment, the machine is equipped with automatic transmission system, anti-floating system, overflow system, heating automatic control system, automatic temperature control system. The speed of the machine is adjustable, the conveying speed is stable, the purpose of automatic continuous production is realized, and the water is controlled at any time. In addition, the conveying net is made of high-strenght high quality stainless steel, the structure is firm, the material is heavy, and the production efficiency is greatly improved. Beautiful appearance, reasonable structure and convenient operation.
