【Lianqi】Specifications of wire mesh cages for erosion gully toe protection and river embankment foundation toe protection
I. Specifications of wire mesh cages for erosion gully toe protection
Mesh specifications
Mainstream sizes: 6×8cm, 8×10cm, 10×12cm, 12×15cm. Some products support customization of larger specifications (e.g., 16×18cm).
Special design: Hexagonal or rectangular mesh is adopted to enhance structural stability.
Wire diameter and material
Wire diameter: 2.0 - 4.0mm. The edge wire is 1mm thicker than the mesh wire to enhance stability.
Surface treatment: Hot-dip galvanizing, electroplating (zinc content 10 - 25g/㎡), high-zinc coating (30 - 300g/㎡), aluminum-zinc alloy coating (10% aluminum content), or PVC/PE coating.
Structural features
Self-permeable design promotes water and soil exchange on the bank slope, suitable for ecological protection of erosion gullies.
Can be filled with stones to form a flexible and self-adaptive protection structure.
II. Common parameters of wire mesh cages for river embankment foundation toe protection
Mesh specifications
Standard sizes: 60×80mm, 80×100mm, 100×120mm, 120×150mm. The products use hexagonal mesh.
Wire diameter and material
Wire diameter: 2.0 - 4.0mm. The edge wire is 1mm thicker.
Surface treatment: High-galvanizing (30 - 300g/㎡), aluminum-zinc alloy coating (10% - 25% aluminum content), or PVC/PE coating.
Application scenarios
Used for river embankment foundation toe protection, providing tensile strength (350 - 550MPa) and elongation (≥12%).
The length (e.g., 1.5 - 4 meters) and depth (e.g., 0.5 meters) can be customized to meet different river embankment needs.
III. Purchase suggestions
Anticorrosion treatment: It is recommended to choose zinc-aluminum alloy or high-zinc coating process for better corrosion resistance.
Customization service: Special mesh or edge wire specifications can be requested for erosion gully toe protection. For river embankment toe protection, attention should be paid to the standardization of length and depth.
Brand and origin: Manufacturers such as those from Anping, Hebei and Anping Lianqi Gabion Mesh Products Co., Ltd. offer a variety of specifications and surface treatment options, which can be selected according to needs.
What is the approximate cost of wire mesh cages for erosion gully toe protection?
What are the construction steps of wire mesh cages for river embankment foundation toe protection?
What is the standard cage spacing of wire mesh cages for erosion gullies?
