Top Quality Sea Salt Refining Machine
US$ 155000.00
≥1 Set
Key Specifications
Get Latest Price
Condition:
New
video outgoing-inspection:
Provided
machinery test report:
Provided
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Factory Price Sea Salt Refining PlantUS$ 155000.00MOQ: 1 Set -
High Quality Edible Table Salt Refining PlantUS$ 155000.00MOQ: 1 Set
-
Fully Automatic Edible Table Food Salt Crushing Washing De-watering Drying Iodine Adding Refining Machine Salt Refinery PlantUS$ 155000.00MOQ: 1 Set
-
Small Scale Industrial Salt Production PlantUS$ 155000.00MOQ: 1 Set
-
Small Scale Edible Table Salt Manufacturing PlantUS$ 155000.00MOQ: 1 Set
Condition
New
video outgoing-inspection
Provided
machinery test report
Provided
core components
Engine, Motor, Gear, Pump
place of origin
China
brand name
genyond
usage
Salt
type
Salt Refining equipment
voltage
380v 50hz
power(w)
60-200kw
weight
1500 KG
dimension(l*w*h)
50x25x10m
warranty
2 Years
Function
Multifunction
Raw material
Raw Crude Salt
Product
White Salt Plant
Capacity
10-100TPD
Method
Physical Washing
Material
SS304/316
Consumption
Low
Processing Types
Complete Processing Line
Certification
iso ce
Applicable Industries
Manufacturing Plant
Showroom Location
None
Marketing Type
Ordinary Product
Warranty of core components
1 Year
Product Description
Rock salt machine include: stainless steel elevator, mixer, conveyor, crusher, salt washing machine, iodize machine, centrifuge and drying machine, dust remover, packing machine and etc.
We can design and manufacture salt machine as per customers’ requirement.
Capacity range from1ton to 50ton/hour.
The four washing is as follows:
First Screw washing
Second screw washing
Stand-up stirring washing
Countercurrent washing
Crude salt |
sea salt,rock salt ... |
Product |
edible iodized salt |
Capacity |
1t/h - 20t/h |
Voltage |
380V 50Hz |
Material |
sus304 + 316L |
Delivery |
70days |
Direction for use
使用说明
Three-crushing is as follows:
First crushing
Wet crushing
Dry crushing
The combination of wet crushing, dry crushing and different ways of washing has greatly improved the salt quality. The above operation is subject to adaptation according to the users’ different requirements due to the use of crude salt of different quality
The following is the technical procedure of our typical ‘four-washing, three-crushing’ technology.
Description of application effect
使用效果描述
Advantage of our salt machine:
1) The high quality refined salt product has high purity, shiny appearance, good free liquidity and stable iodine content.
2) Low loss, the loss of NaCl is under 10%.
3) Low energy consumption and investment.
4) Equipment has long service life, easy to operate and maintain.
Detailed Images
The four washing is as follows:
First Screw washing
Second screw washing
Stand-up stirring washing
Countercurrent washing
Three-crushing is as follows:
First crushing
Wet crushing
Dry crushing
The combination of wet crushing, dry crushing and different ways of washing has greatly improved the salt quality. The above operation is subject to adaptation according to the users’ different requirements due to the use of crude salt of different quality
The following is the technical procedure of our typical ‘four-washing, three-crushing’ technology.
Size Information
Capacity |
1t/h |
3t/h |
5t/h |
10t/h |
20t/h |
Power |
100kw |
125kw |
140kw |
200kw |
270kw |
Production area |
500sqm |
700sqm |
800sqm |
1200sqm |
1500sqm |
