CE Certificate Approved 40FT Shipping Container Chassis Skeleton/Skeletal Truck Semi Trailer With Steel Cargo Box/Van
Product Spotlights
Product Description
3 Axles 40FT 45FT Semi Gooseneck Trailer Skeleton Container Chassis
| Item | Unit | Quantity | Notice |
| Overall dimension | detail according to the drawing | ||
| Axle | piece | 3 | FUWA-13T |
| Tyre | piece | 12 | 11R20-16PR,Triangle Tire without spare tire |
| Rim | piece | 12 | 8.0-20 |
| Leaf spring | piece | 6 | 90width*10pieces*12 thickness |
| Braking system | set | 2 line air braking system with air tank ,emergency relay valve,braking chambers and mechanical slack adjusters. | |
| Electrical system | set | 1 | 24 volt electrical system.7 pin electrical connector.parking .stop,reverse,number plate and indicator lights.rear lights conform to European standard,rear front and side reflectors |
| Suspension | set | 3 | Standard Suspension |
| Relay valve | whole vehicle | 1 | WABCO |
| Landing gear | pair | 1 | JOST C200 |
| Kingpin 2" | piece | 1 | 50# Welded |
| Tie-in | piece | 2 | haldex |
| Chamber | piece | 2 | stored chamber 2 units T30/30 |
| Upper and lower wing plates | 14/16mm,width146mm, using the highly quality Q345 steel, |
||
| Twist locks | 12 | can load 1*40ft,2*20ft,1*20ft container | |
| Main beam | height: 500mm webplate:6mm using the highly quality Q345 steel |
||
| Reflectors | Red triangle reflectors at the rear of the trailer and on side | ||
| Spare tyre carrier | 2 | standard | |
| Color | according to required on customer |
The skeleton trailer is mainly for containers transportation, it can be customized:
1-trailers for 20ft,30ft,40ft,45ft,48ft,50ft,53ft container shipping
2-flatbed or skeleton chassis type
3-Main beam:500mm height
4-material of the main beam: Q345
5-Suspension: spring suspension, Rigid, single point, bogie or air suspension
6-Axles number: 2 3 4 axles.
8-Jost landing gear, FUWA axles and Tri-angle tires
9-extendable or sliding type optional
Our Flatbed trailers advantages:
**Modern design: Double-Groove vertical van, light-weight I beam, arched form longitudinal beams, that make the trailers
structure super strong and superlight;
**Sound Adaptability: Passed the special processing, the overall frames of the traielrs can stand the actual test of various
road conditions.
**Superior Material selection: The raw materials are bought from top 5 Steel Mills, and all of other parts are all from top
suppliers also, like Triangle tyres, Jost landing gear, WEBCO relay valve, we have strict selection requirement for vendors.
**Top configurations: Ensure every trailers with high configurations to decrease the maintaince for clients, and improve the
trailers with longer service time
