Rice/Wheat/Corn/Maize Flour Production Equipment/ Mills Processing/ Flour Milling Machinery Price
US$ 80000.00
1 Set
US$ 76000.00
≥2 Set
Key Specifications
Get Latest Price
Type:
APPLE POWDER process line
brand name:
GENYOND
place of origin:
Shanghai, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Automatic Coconut Flakes Drying Machine / Coconut Shred DryerUS$ 150000.00MOQ: 1 Set -
Spray Dryer/Spray Drying Machine/fruit and Vegetable Powder Production LineUS$ 36800.00 - 39000.00MOQ: 1 Set
-
Instant Powder Pressure Spray Dryer for Ceramic Tile Plant With Factory ServiceUS$ 9000.00MOQ: 1 Set
-
Shanghai Factory Centrifugal Coffee Spray Dryer Equipment Banana Powder High Pressure Spray Dryer Spraying Drying Tower MachineUS$ 9800.00MOQ: 1 Set
-
Fluid Bed Dryer Granulator/high Efficiency Rotary Dryer for SaleUS$ 10000.00 - 11111.00MOQ: 1 Set
brand name
GENYOND
place of origin
Shanghai, China
voltage
220/380V
power(w)
140KW
dimension(l*w*h)
23000X1800X1900MM
weight
23t
warranty
2 Years
application fields
Flour Mill
machinery function
milling
raw material
Wheat, Corn, Flour, Soybean
output product name
flour
After-sales Service Provided
Field installation, commissioning and training, Engineers available to service machinery overseas
GRADE
food grade
materials
stainless steel
Certification
iso ce
Applicable Industries
Manufacturing Plant, Food & Beverage Factory, Restaurant, Retail
1 Name flour milling machine
2 Capacity 10-500T/D
3 Quality Pass the quality management system ISO9001. Quality guarantee period of one year.
4 Service turnkey project,special design, installation, commissioning and training workers,lifelong service to our product.
5 Spare parts All of our new equipment to contain one year free spare parts
6 Workshop according to the capacity
7 Power supply according to the capacity
8 Color Red,green,white,blue or according the customer's demand
9 Cleaning system beating, screening, destoner, magnetic separator and dampening.
10 Milling system roller mill, plansifter, purifier, impact detacher, etc
11 packing and stacking The packing part can be manual one also can be auto one, this can be designed according to requirement and machine capacity.
12 Storage silos, or warehouse
10T per day machine list for reference
No |
Equipment |
Quantity |
Power(kw) |
Remark |
1 |
Versatile cleaner |
1set |
2.2 |
Clean raw maize |
2 |
Screw conveyor |
1set |
1.1 |
Wet corn in the way of elevate maize to peeling machine |
3 |
Peeling machine |
1set |
11 |
Remove husks and germ from maize |
4 |
Hammer mill |
1set |
4 |
Crush the maize |
5 |
Roller mill |
2sets |
7.5*2 |
Mill the maize |
6 |
Sifting machine |
3sets |
2.2 |
Grade the flour |
7 |
Bran finisher |
1set |
1.1 |
Separate bran from corn core |
8 |
High pressure air blower |
1set |
7.5 |
Supply air conveying |
9 |
Air lock |
5sets |
1.1 |
|
10 |
Pipelines |
1set |
|
|
11 |
Electric cabinet |
1set |
|
Control the machines |
12 |
Bag filter |
1set |
|
Collect dust |
13 |
Support for machines |
1set |
|
|
14 |
Steel structure |
1set |
|
|
15 |
Screws |
1set |
|
|
16 |
V-belt |
1set |
|
|
17 |
Flange |
1set |
|
|
18 |
Pipe clamp |
1set |
|
|
19 |
Chains&gear parts |
1set |
|
|
20 |
Motor |
1set |
|
|
21 |
Spare parts for one year |
1set |
|
|
Capacity |
10T/24H input maize |
Space required |
7*2.5*3.2m(L*W*H) |
Power supply |
About 45.2kw |
Total weight |
About 3500kg |
Package |
One 20feet container |
Output yield |
Maize flour:70-75%(60-80M); Animal feed:25-30% |
