Food Freezing Machine for Freeze Dried Fruits and Vegetables

Food Freezing Machine for Freeze Dried Fruits and Vegetables photo-1
Food Freezing Machine for Freeze Dried Fruits and Vegetables photo-2
Food Freezing Machine for Freeze Dried Fruits and Vegetables photo-3
Food Freezing Machine for Freeze Dried Fruits and Vegetables photo-4
Food Freezing Machine for Freeze Dried Fruits and Vegetables photo-5
Food Freezing Machine for Freeze Dried Fruits and Vegetables photo-6
US$ 8000.00 1 - 4 Set
US$ 7200.00 ≥5 Set
Key Specifications
Get Latest Price
Type:
Vacuum Freeze-drying Equipment
type:
Vacuum Drying Equipment
Drying Capacity (kg):
5, 10, 15, 20, 25
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
type Vacuum Drying Equipment
Drying Capacity (kg) 5, 10, 15, 20, 25
application Food Processing
place of origin Shanghai, China
brand name GENYOND
voltage 220 V, 380 V, 110 V, 480 V
power(w) 300 W
dimension(l*w*h) 2150*1280*2000MM
key selling points Automatic, Multifunctional, High Safety Level, Competitive Price, Energy Saving
warranty 1 Year
weight (kg) 200
machinery test report Provided
video outgoing-inspection Provided
core components Bearing, Pump, Gear
heating method Gas Heating, Electric Heating, Steam Heating, Oil Heating
material SUS304, SUS304L, SUS316, SUS316L
Product name Dryer Machine
Name Industrial Freeze Dryer Machine
Function Food Vegetable Fruit Dehydrator
After-sales Service Provided Online Support
Dryig process Continuous Automatic Drying
MOQ 1 Set
Certification CE Certificate
Package Wooden Case
Brand GENYOND
Product Introduce

Food Freezing Machine for Freeze Dried Fruits and Vegetables

1.Drying adopts radiation heat exchange, with uniform temperature and high heat exchange efficiency; Conduction heating method without directly placing product trays on heating plates

2.The raw materials are pre frozen to below -18 ℃ using an external dedicated quick freezing device; Directly freezing without using the internal heat transfer shelf of the tank;

3.The multi cold hydrazine system ensures the lowest operating cost of the equipment.

4.Short downtime between drying batches and increased production output.

5.The condensation capacity of cold hydrazine remains constant, and the ice layer of cold hydrazine remains at 3-5mm, resulting in high condensation efficiency and low energy consumption;
Product Specification
Specification
LG-1
LG-5
LG-10
LG-20
LG-30
LG-50
LG-100
Shelf area
1 ㎡
5 ㎡
10 ㎡
20 ㎡
30 ㎡
50 ㎡
100 ㎡
Input capacity
10kg
50kg
100kg
200kg
300kg
500kg
1000kg
Shelf number(Layers)
4+1
6+1
8+1
8+1
13+1
15+1
15+1
Shelf spacing
60mm
60mm
65mm
80mm
90mm
90mm
90mm
Max. Water capture/batch
≥60kg/h
≥60kg/h
≥120kg/h
≥200kg/h
≥500kg/h
≥800kg/h
≥1600kg/h
Cooling water
/
10m³/h
20m³/h
40m³/h
60m³/h
80m³/h
160m³/h
