UHMWPE wheels are light in weight but have a very high load-carrying capacity, higher wear resistance, as well as high impact strength.
Product Description
Our UHMWPE pulley Characters:
1.rust-proof. It can work well in the humid environment.
2.self lubricating without oil.
3.wear resistance
rrosion resistance.
5.noise reduction
6.light weight
7.high impact resistance
Features of UHMW pulleys
Extremely high anti-abrasion;
Excellent self-lubricating performance;
Good in resisting impact, flexibility;
Being excellent in resisting chemical corrosion(acid, alkali, salt);
Being free from toxin, smell or exudates;
Good electric resistance;
Low in water absorption;
Low coefficient of friction;
Resisting environment and anti-aging;
Resisting low temperature;
UV resistance
UHMW Pulley Technical parameters:
| Property | Unit | Value |
| Density | g/cm3 | 0.93-0.96 |
| Average molecular weight | g/mol | 3million- 10 million |
| Tensile strength (23°C in air) | MPa | 22 |
| Breaking strength | MPa | 42 |
| Tensile strain at break | % | 600 |
| Charpy impact strength (notched) | mJ/mm2 | No break |
| Ball indentation hardness | N/mm2 | 42 |
| Shore D hardness | -- | 65-70 |
| Abrasion | % | 70-80, steel = 100 |
| Static Friction Coefficient | -- | ≤0.16 |
| Kinetic Friction Coefficient | -- | ≤0.10 |
| Water Absorption | -- | NIL |
| Elongation at break at 23 degress | % | ≥300 |
| Temperature resistance | °C | -269 to +85 |
| Melt Temperature | °C | 130-140 |
UHMW Material Type:
1.UHMWPE 3million--9million molecule weight
TICONA, TIVAR is also available
2.HDPE
UHMW pulley Color
Packaging & Shipping
By carbon, pallet according to the quantity or the customer requirements
Our Services
1.Any inquiry will be replied within 6 hours.
2.If your quantity is small, it is OK too.
3.We can make the products according to your drawing or sample.
4.The raw material of Ticona or the Tivar is available.
5.The UHMW products of 3million to 10 million molecular weight are for your option.
FAQ
1.Why to choose UHMWPE?
What makes UHMWPE such a distinctive and useful engineering plastic is its combination of excellent properties, which are; outstanding abrasion resistance, superior impact resistance, non-sticking and self-lubricating and excellent mechanical properties, even in cryogenic condition
2.What color you can offer?
Black, natural, red, green, blue, grey, yellow and so on are available.
We can offer the cut-to-size products according to your requirements.
3.Sample is OK?
Small size of samples are free,you only need to pay for the shipping cost,or you can provide your UPS,DHL,Fedex,TNT courier account to us.
4.stock or not?
It depends on the products you need. Welcome to contact us for inquiry.
5.Can you make the custom machined products?
Yes. We have the our own machining shop.
6. Payment?
Normally, TT. 30% deposit and the remaining payment before leaving the factory.(other payment methods are negociatable)
