Good Quality Tomato Ketchup Production Line / Tomato Sauce Processing Plant From China
US$ 200000 - 1000000
MOQ: 1 Set
Key Specifications
Get Latest Price
Power:
CUSTOMIZED
brand name:
GENYOND
dimension(l*w*h):
CUSTOMIZED
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Complete Fruit Juice Production Line Strawberry Processing Line Berry FruitsUS$ 6800.00 - 8300.00MOQ: 1 Set -
Industrial Automatic Large Capacity Carrot Processing Line New Vegetables Production Line for SaleUS$ 13990.00 - 14800.00MOQ: 1 Set
-
Semi-automatic Complete Fruits Processing Line Passion Fruit and Dragon Fruit Production Line for SaleUS$ 28900.00 - 32000.00MOQ: 1 Set
-
Commercial Customized Fully Automatic Coconut Processing Line Coconut Juice Equipment Coconut Cutting MachineUS$ 16000.00 - 18500.00MOQ: 1 Set
-
Big Promotion Red Dates Washing Semi-automatic Dates Processing Line Complete Mdelar Production LineUS$ 31800.00 - 34000.00MOQ: 1 Set
brand name
GENYOND
dimension(l*w*h)
CUSTOMIZED
place of origin
Other Country
automatic grade
Automatic
voltage
220V 380V
power
100kw
Capacity
1-20t/h, 1-20T/h
key machines
Tomato paste transfer system, Tomato ketchup ingredients dissolving system, Tomato ketchup blending tank, Tomato ketchup high-Pressure homogenizer, Tomato ketchup degasser and inline pasteurizer, Tomato sauce or ketchup filling machine
product type
Vegetables, Fruit, Tomato
Name
tomato ketchup production line
Material
304 Stainless Steel
Raw material
fresh tomato
MOQ
1 Set
Processing Types
Automatic
Certification
ISO CE
Condition
New
Year
2024
Weight
1000 KG
Product Description
Tomato Ketchup Production Line
Tomato sauce/ketchup production line use tomato paste (28-30 Brix or 36-38 Brix) as main raw materials, then use pure water (RO water) to dilute tomato paste into 20-22brix or 12-14 Brix sauce or ketchup, to increase flavor and shelf life, salt, sugar, vinegar, starch, antiseptic(Sodium benzoate, potassium sorbate) need to be added. After that, we use one blending tank to mix allthe ingredients, then through homogenizing, degassing and pasteurizing, we fill the tomato ketchup/sauce into small four sealed bags, tin cans, bottles, doypacks or brick cartons. To extend the shelf life of the tomato ketchup, The filling should be hot filling(85-89℃) as tomato ketchup is rich in nutrients, after hot filling, we use water bath pasteurizer or spray type pasteurizing cooling tunnel to do the secondary pasteurizing, and then cooling tomato ketchup from 80℃ to ambient temperature 30℃, then packing the containers into cartons or shrink package for consumption.
All ingredients are dosed by weighing or flow meter to ensure the accuracy of the proportion of each material.
The whole production line includes RO water generating system, hot water generating system, tomato paste transfer system, tomato sauce ingredients dissolving system, tomato ketchup preparation and mixing system, homogenizing, degassing and pasteurizing system, tomato ketchup filling machine, tomato ketchup in containers secondary pasteurizing machine and CIP system. It can be designed with continuous production or batch production according to the client’s budget and production capacity.
The tomato ketchup making machine is made of SUS304 food-grade material. After each production is completed, the CIP cleaning system will thoroughly clean the entire material pipeline and storage tank, filling machine, material pump, and sterilization machine to ensure that each batch of products is high-quality and hygienic.
The ketchup production process involves blending the concentrated tomato paste with water, vinegar, sugar, salt, and spices, heating the mixture to dissolve the solids and reduce it to a desired consistency, filtering out any remaining impurities, bottling or canning the ketchup, and finally, pasteurizing it to ensure safety and longevity on shelves as a popular condiment for various food dishes.
The capacity of the tomato ketchup making machine is from 500L/H-5000L/H available for clients to choose from.
The end products of tomato sauce or ketchup processing plant can be filled into bottles, tubes, tin cans, pouches, sachets or glass jars.
Processing Flow
Specification
Name |
Tomato ketchup production line |
Raw material |
Concentrated tomato paste, pure water, sugar, salt etc. |
Output product |
Tomato ketchup |
Capacity |
1 Ton/h to 50 Ton/h |
Control |
Automatic PLC control |
Material |
High quality Stainless steel 304 or 316 |
Delivery time |
45-90 days according to the capacity |
Production Line
