Product Composition
This investment casting wax is formulated with high-quality paraffin wax and microcrystalline wax as the primary raw materials, compounded with carefully selected additives through precise blending processes. Each component is optimized for consistent performance, ensuring excellent stability and compatibility to meet the stringent requirements of precision lost wax casting.
Main Applications
Designed as a low-to-medium temperature pattern material for investment casting, this wax is widely used across industries requiring high-precision metal component production, including:
Electronics Manufacturing: Ideal for small, high-precision components such as connectors, sensor housings, and miniature mechanical parts
General Machinery: Suitable for automotive parts, hardware tools, transmission components, and medium-to-large structural castings
Aerospace: Perfect for high-end applications like aero-engine components, aviation accessories, and complex aerospace casting
Key Product Features
Available in white or pale yellow solid form, this casting wax offers outstanding performance characteristics tailored for precision casting processes:
Superior Surface Quality: Excellent gloss and smooth finish, minimizing surface defects such as porosity and roughness to reduce post-casting machining costs
High Mechanical Strength: High hardness and rigidity prevent deformation, cracking, or dimensional shift during pattern making, ensuring accurate replication of complex part geometries
Long Service Life & Recyclability: Low loss rate with proper recycling and reprocessing, supporting repeated use and effectively reducing raw material costs
Optimal Process Performance: Good fluidity for uniform mold filling, low shrinkage for dimensional accuracy, and clean dewaxing with minimal residual ash to avoid casting defects
Precautions
Storage & Transportation: Keep packaging intact to avoid damage, moisture, or extrusion during transit. Store in a dry, well-ventilated area at temperatures below 50°C, away from direct sunlight.
Fire Safety: Classified as a flammable material; keep away from open flames, ignition sources, and heat. Ensure fire safety equipment is available in the storage area.
Handling: Follow industrial safety protocols when using the product. Avoid prolonged direct skin contact, and wash hands thoroughly after handling.
Specifications & Packaging
Packaging: 50kg per moisture-proof industrial bag, suitable for bulk transportation and storage. Custom packaging options are available upon request.
Compliance: Manufactured in strict accordance with the industry standard Q/SH3135 158-2007, with multi-stage quality inspections to ensure consistent batch-to-batch performance.
Main Technical Indicators
| Test Item | Unit | Low-Temp Grade | Medium-Temp Grade | Test Standard |
|---|---|---|---|---|
| Drop Melting Point | °C | Min. 58 | Min. 60 | GB/T 8026 |
| Penetration (25g, 25°C) | 1/10mm | Max. 18 | Max. 10 | GB/T 4985 |
| Ash Content | % | Max. 0.1 | Max. 0.1 | GB/T 508 |
| Volume Shrinkage | % | Max. 2 | Max. 1 | GB/T 14235.4 |
| Flexural Strength | MPa | Min. 2 | Min. 4 | GB/T 14235.3 |
Brand & Support
Brand: JSYA
Service: We provide professional technical support and customized solutions based on your casting process requirements. Our responsive after-sales team ensures quick resolution of any quality issues to keep your production running smoothly.
