Shanghai GENYOND Customized Double Effect Falling Film Evaporator Equipment for Sale
US$ 35200.00
1 - 4 Set
US$ 32800.00
≥5 Set
Key Specifications
Get Latest Price
Material:
Stainless Steel
video outgoing-inspection:
Provided
machinery test report:
Provided
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Continuous Sterilization & Concentration Falling Evaporator Double Effect Falling Film EvaporatorUS$ 54200.00 - 57000.00MOQ: 1 Set -
Enency Saving Low Consumption Evaporating Structure Forced Circulating EvaporatorUS$ 20000.00 - 23400.00MOQ: 1 Set
-
Tomato Paste Automatic Evaporator Machine Forced Circulating Evaporato for SaleUS$ 24200.00 - 25000.00MOQ: 1 Set
-
Concentration Vacuum Evaporator Forced Circulating Evaporator MachineUS$ 36500.00 - 38900.00MOQ: 1 Set
-
GENYOND Brand Evaporator Machine Milk Industry Forced Circulating Evaporator EquipmentUS$ 22000.00 - 24200.00MOQ: 1 Set
Material
Stainless Steel
video outgoing-inspection
Provided
machinery test report
Provided
core components
Engine, PLC, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump
Power Source
Electric
Processing
Evaporator
place of origin
Shanghai, China
brand name
GENYOND
voltage
110V~480V
Power(w)
50KW
dimension(l*w*h)
5500*3500*11000MM
Volume(L)
100 L, 200 L, 500 L, 1000 L
warranty
1 Year
key selling points
Automatic, Easy To Operate, High Productivity, High Safety Level
Operating Temperature
0-100°c
Weight (KG)
220
Product name
Falling Film Evaporator
After-sales Service Provided
Video Technical Support
After Warranty Service
Online Video Technical Support
Brand
GENYOND
Evaporation Type
Middle Temperature
Product Introduce
Large Production Capacity Evaporator Machine Double Falling Film Evaporator
Falling film evaporation is to add the material liquid from the upper end of the heating chamber and distribute it evenly into the heat exchange tubes through the liquid distribution and film forming device. Under the action of gravity, vacuum induction and air flow, it becomes a uniform film. Flow from top to bottom. During the flow process, it is heated and vaporized by the heating medium in the shell side, and the generated vapor and liquid phase enter the separation chamber of the evaporator together. After
the vapor and liquid are fully separated, the vapor enters the condenser for condensation (single-effect operation) or enters the next-effect evaporator as the medium is heated to achieve multi-effect operation, and the liquid phase is discharged from the separation chamber.
the vapor and liquid are fully separated, the vapor enters the condenser for condensation (single-effect operation) or enters the next-effect evaporator as the medium is heated to achieve multi-effect operation, and the liquid phase is discharged from the separation chamber.
Product Specification
Model |
YNHS-2500 |
YNHS-3000 |
YNHS-3200 |
YNHS-5000 |
YNHS-6400 |
YNHS-8000 |
|||||
Moisture evaporation(kg/h) |
2500 |
3000 |
3200 |
5000 |
6400 |
8000 |
|||||
First effect evaporation temperature(℃） |
68~72 |
||||||||||
Second effect evaporation temperature(℃） |
45~52 |
45~52 |
55~60 |
55~60 |
55~60 |
55~64 |
|||||
Steam consumption(kg/h) |
18 |
21 |
25 |
32 |
40 |
44 |
|||||
Size(m) |
5.5*4*11 |
5*3.5*11 |
6.5*4*11 |
7.3*4*12 |
7.3*4*12 |
9.3*4*12 |
|||||
