Home > Manufacturing & Processing Machinery > Machinery for Food, Beverage & Cereal > Dairy Processing Machinery > Processed Cheese Processing Line Dairy Cheese Steam Cooker
Processed Cheese Processing Line Dairy Cheese Steam Cooker
US$ 150000.00
1 Set
US$ 125000.00
≥2 Set
Key Specifications
Get Latest Price
video outgoing-inspection:
Provided
machinery test report:
Provided
core components:
PLC, Motor
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
500ml~1000ml Complete Drinking Water Filling Production Line Fruit Juice Filling Soft Drink Filling PET Bottle Filling LineUS$ 22000.00MOQ: 1 Set -
Mozzarella Cheese/ Cheese Butter/ Cream Butter Cooker Melting MachineUS$ 45000.00MOQ: 1 Set
-
Table Top 3 Flavors Mini Soft Ice Cream Machine Price/ Small Ice Cream MakerUS$ 590.00 - 630.00MOQ: 1 Set
-
Hot Sale High Quality Wholesale Commercial Stand & Table Top Ice Cream Machine 3 Flavor Soft Serve Ice Cream Maker MachineUS$ 590.00 - 630.00MOQ: 1 Set
-
CHEAP PRICE Table Top Small Soft Ice Cream Making MachineUS$ 590.00 - 660.00MOQ: 1 Set
video outgoing-inspection
Provided
machinery test report
Provided
core components
PLC, Motor
place of origin
Shanghai, China
brand name
Genyond
voltage
440V
power(w)
55 kW
weight
1500 KG
dimension(l*w*h)
Standard Size
warranty
1 Year
key selling points
Famous brand PLC
After-sales Service Provided
Engineers available to service machinery overseas
Material
SUS304/SUS316
Product name
cheese cooker
Final product
cheese,sauce,butter
Capacity
500L
Function
Industry Emulsion
Processing
cutting heating mixing
Raw material
cream cheese, fruit sauce, mixing ingredient
Processing Types
plc controlled process
Applicable Industries
Food & Beverage Factory
Showroom Location
None
Marketing Type
New Product 2020
Warranty of core components
1 Year
Condition
New
Product Description
Application:
The cheese production process
Seasoning, sauce production
Baby food production
Butter production process
Various types of candy production process
Mayonnaise, ketchup production
Processing of various types of frozen food that can be refrigerated.
Pharmaceutical production process.
Parameters:
Volume: 50-500 L
Inner pot pressure: 0-0.1 Mpa
Max working pressure inside: 0.08 Mpa
Max vacuum degree: -0.95 Mpa
Safe valve detonation pressure: 0.08 Mpa
Inner pot design temperature: -30~100 ℃
Inside working temperature: -25~95 ℃
Inside testing water pressure: 0.13 Mpa
Designed jacket pressure: 0.24 Mpa
Max jacket working pressure: 0.2 Mpa
Jacket working pressure: 133 ℃
Pure steam pressure: 0.2~0.35 Mpa(inlet pot)
Power: 3P, 380V, 50Hz or customized
Control power: 24V DC 50 W
Main knife power: 20-50 kW
Main motor speed: 300-2900 r/min
Mixing motor power: 1.5 kW
Mixing motor speed: 24 r/min
Detailed Images
Spindle kinematics
It is mainly composed of main motor, main shaft, bearing, coupling, fluororubber packing seal, blade, etc.
They provide power for cutting, pulverizing, and mixing materials.
Mixing scrapper
It is mainly composed of motor, reducer, stirring shaft, scraping wall stirring blade, bearing, seal and so on.
They play the role of stirring and scraping the material.
Auto cap open
Flow rate: 500L/h
Material: SUS304
Certifications
Packing & Delivery
PACKAGE
Standard export carton or wooden cases packing.
DELIVERY TIME:
7-20 days after confirming order,detail delivery date should be decided according to production season and order quantity.
