As a professional manufacturer with ISO9001 certification and a strong global presence across North America, Europe, Asia, and beyond, Jinhua Dika Electrical Equipment Co., Ltd. specializes in delivering reliable industrial components like this high-performance LED Push Button Switch. Designed for demanding control panel applications, this switch combines clear visual feedback with exceptional durability and a responsive spring rebound mechanism, ensuring precise operation and long-term reliability in industrial environments.
Key Features & Technical Advantages:
- Engineered for Longevity: Built to withstand over 50,000 mechanical operations, significantly reducing maintenance frequency and replacement costs.
- Instant Tactile Feedback: The robust spring rebound mechanism guarantees a crisp, positive action and immediate return after each press, enhancing operator control and preventing accidental holds.
- Clear Visual Status Indication: Integrated high-brightness LED provides unmistakable operational status (e.g., power on, activation, fault), improving safety and reducing operator errors.
- Rugged Industrial Construction: Features a thermoplastic body rated UL94 V-0 for flame retardancy and silver alloy contacts for reliable current switching under the specified rating.
- Environmental Protection: Achieves IP65 rating on the front panel, offering excellent resistance against dust ingress and low-pressure water jets, suitable for harsh factory settings.
- Easy Installation & Compatibility: Standard 22mm panel cutout ensures compatibility with a wide range of control cabinets and enclosures globally. Secured by a nut from the rear.
Technical Specifications:
| Parameter | Specification |
|---|---|
| Electrical Rating | 10A, 250V AC (Resistive Load) |
| Contact Configuration | 1NO (SPST Normally Open) |
| LED Voltage | Standard: 12V/24V DC (Other voltages optional) |
| LED Color Options | Red, Green, Yellow, Blue, White (Customizable) |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Contact Resistance | < 50mΩ (Initial) |
| Insulation Resistance | > 100MΩ (500VDC) |
| Dielectric Strength | 2000VAC (1 min between contacts & shell) |
Why Choose Our LED Push Button Switch?
- Enhanced Operational Efficiency: The combination of tactile feedback and clear LED signaling streamlines machine operation and monitoring.
- Reduced Downtime: The proven 50,000+ cycle lifespan minimizes unexpected failures and maintenance interventions.
- Improved Safety Compliance: Clear visual indicators and reliable switching contribute to safer plant operation and accident prevention.
- Global Compatibility: Designed to meet the needs of diverse industrial markets worldwide, supported by our extensive export experience (North America, South America, Europe, Asia, Africa, Oceania).
- Cost-Effective Solution: Offers a strong balance of performance, durability, and value for OEMs and panel builders.
Backed by Jinhua Dika's commitment to quality through ISO9001 certified manufacturing processes and supported by an annual export volume exceeding US$1 Million to markets spanning North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, and beyond, this LED Push Button Switch represents a reliable and proven component choice. Our experienced team (11-50 dedicated employees) ensures consistent product quality and efficient logistics from major Chinese ports like Shanghai, Tianjin, Guangzhou, and Ningbo. Experience the difference robust engineering and global reliability make – contact us today for competitive pricing, volume discounts, or to discuss custom requirements for your control panel projects.
Frequently Asked Questions (FAQ):
Q1: How is the 50,000 cycle life guaranteed?
A1: The 50,000 cycle rating is based on rigorous laboratory testing under standard load conditions (10A/250VAC resistive). This mechanical life expectancy reflects the switch's robust internal spring and contact design.
Q2: Can I get different LED colors besides the standard ones?
A2: Yes, customization is available. We offer various standard colors (Red, Green, Yellow, Blue, White). Other colors or specific wavelengths can be discussed based on MOQ.
Q3: Is the LED voltage customizable?
A3: Absolutely. While 12V/24V DC are standard, we can provide switches with LEDs compatible with other common voltages (e.g., 5V, 48V, 110V, 220V AC/DC) upon request.
Q4: What does the IP65 rating cover?
A4: The IP65 rating applies to the front face of the switch when properly mounted. It ensures protection against dust ingress (complete) and low-pressure water jets from any direction, making it suitable for washdown environments or dusty areas.
Q5: Are these switches compliant with international safety standards?
A5: Our manufacturing process is ISO9001 certified, ensuring consistent quality control. While the product incorporates robust materials (UL94 V-0 thermoplastic), specific end-use compliance (e.g., UL, CE) depends on the final application and system integration. Certificates for specific standards can be discussed.
Q6: What is the lead time for standard and custom orders?
A6: Standard configurations typically have shorter lead times. For exact lead times based on order quantity and specific customization (color, voltage), please contact our sales team directly. We prioritize efficient delivery from our Zhejiang base.
Q7: Do you offer different actuator shapes or legends?
A7: Yes, options like flat, domed, or mushroom head actuators may be available. Custom actuator legends (symbols or text) can also be produced for larger volume orders.
Q8: What is the minimum order quantity (MOQ)?
A8: MOQ varies depending on the configuration. Standard items often have lower MOQs. For custom requirements (LED color/voltage, legend), the MOQ will be higher. Contact us for specific details tailored to your needs.
