Jinhua Dika Electrical Equipment Co., Ltd., an ISO9001-certified manufacturer with over $1M annual exports, presents a robust solution for electrical cabinet protection. Our 220V AC Electrical Cabinet Dehumidifier combines IP65 waterproof integrity with intelligent control to prevent moisture damage in critical industrial environments across 15+ global markets.
Core Advantages:
- Eliminates Condensation: Prevents short circuits and corrosion in enclosures
- All-Weather Operation: IP65 rating ensures reliability in harsh conditions
- Energy-Smart: Auto-sensing technology activates only when needed
- Zero Maintenance: Peltier (thermoelectric) system with no compressors or refrigerants
Technical Specifications:
| Parameter | Specification |
| Power Supply | 220V AC ±10% |
| Power Consumption | ≤50W |
| Operating Temp | -20°C to 55°C |
| Humidity Range | 30% RH to 95% RH |
| Drainage | Evaporative or external tube |
Smart Control Features:
- Auto-restart after power failure
- LED operation indicators
- Adjustable humidity threshold (40-80% RH)
- Frost protection mode
Why Global Buyers Trust Dika: With shipments from Shanghai/Tianjin/Guangzhou/Ningbo to North America, Europe, Asia, and beyond, we serve OEMs and utilities in 30+ countries. Our 11-50 person team maintains strict ISO9001 processes, ensuring every unit delivers:
- 15% longer component lifespan in electrical cabinets
- Reduced downtime due to moisture-related faults
- Compatibility with PLC systems via optional dry contacts
FAQ Section
Q: How does IP65 rating protect the dehumidifier?
A: The sealed housing results dust ingress and low-pressure water jets from any direction, making it suitable for outdoor cabinets.
Q: Can it be installed in live cabinets?
A: Yes, designed for safe installation without cabinet shutdown using DIN rail or screw mounting.
Q: What's the typical dehumidification cycle?
A: The smart sensor activates 4-8 times daily depending on ambient humidity, each cycle lasting 10-15 minutes.
Q: Is remote monitoring possible?
A: Models with RS485/Modbus protocol are available upon request for SCADA integration.
Q: How to handle drained water?
A: Condensate evaporates automatically in standard mode, or connect an external tube for direct drainage.
Q: What cabinet sizes is this suitable for?
A: Optimized for 0.5-3m³ enclosures. For larger spaces, multiple units can be deployed.
Q: Certifications beyond ISO9001?
A> Contact us for specific certification requirements in your region.
