Help CenterDouble Head Boring Machine for Rotogravure Steel Base Cylinder Processing
Related Products
-
Flange Welding Machine for Gravure Printing Cylinder Steel Base CylinderNegotiableMOQ: 1 Set -
High Precision CNC Lathe Machine for Gravure Cylinder Steel Base Shell CylinderNegotiableMOQ: 1 Set
-
Dynamic Balancing Machine for Gravure Cylinder Steel Base Shell CylinderNegotiableMOQ: 1 Set
-
Horizontal Hydraulic Keyway Slotting Machine Broaching Machine for Gravure Cylinder Steel Base Shell CylinderNegotiableMOQ: 1 Set
-
Steel Plate Rolling Machine Bending Machine for Gravure Cylinder Steel Base Shell CylinderNegotiableMOQ: 1 Set
The double-head boring machine is designed to machine both end sides of a cylinder simultaneously. Its tooling is used for tapered hole processing, as well as integrated machining of flat end faces, welding seams, and outer circular chamfers. The machine features double tool holders, a four-axis servo control system, an integrated cast bed, and rectangular guide rails. With sufficient strength, rigidity, and good shock absorption, the machine tool ensures stable performance. Additionally, the double-head boring machine has a compact tool structure.
Cylinder diameter: Φ100-350mm
Cylinder length: 450-1300mm
Bore diameter: Φ60-200mm
Bore pitch: 0-45°
Rotating speed: 60-300r/min
Movement speed of glide path: 10m/min
Movement speed of upglide path: 10m/min
Compressed air: 0.5-0.6MPa
Power supply: AC220/380 45A
Total power: 13.7kw
