Ppgi Color Wood Grain Coated Steel Coil
The first step in producing high-quality 2D and 3D wood-grain color-coated coils is cleaning and degreasing the steel strip, followed by pre-treatments like pickling to enhance the adhesion of subsequent coatings. Next, a primer is sprayed on to create a uniform base color, providing the foundation for the subsequent wood-grain effect.
The core of wood-grain color-coated coils lies in wood-grain transfer technology. This process uses a special transfer film to precisely transfer the natural wood grain pattern to the steel coil surface. During the transfer process, high temperature and pressure are used to firmly adhere the wood grain pattern to the metal surface, mimicking the texture and color variations of real wood.
The innovative highlight of 3D wood-grain color-coated coils lies in their realistic wood grain appearance, which can add a warm and natural atmosphere to building exterior walls, interiors, roofs, and other spaces. Even in environments where solid wood is not suitable, the wood-like visual effect can be achieved, saving space and decoration costs.
Location |
category |
value |
||
Executive standard |
National standard |
GB/T12754-2019 |
||
American Standard/European Standard |
ASTM A792M |
|||
Cold rolled substrate |
Width specification |
Cold rolled substrate thickness |
Including metallized layer, the thickness after painting |
Label thickness |
1200mm |
≥0.41mm |
≥0.46mm |
≥0.45mm |
|
Size deviation |
Width tolerance |
Upper deviation +4mm |
||
Lower deviation 0 |
||||
thickness |
Upper deviation +0.05mm |
|||
Lower deviation 0 |
||||
Yield Strength |
>300MPA |
|||
tensile strength |
270-500MPA |
|||
elongation after break |
More than 20% |
|||
Steel coil inner diameter |
Standard: 508mm,Except for other agreements |
|||
metal coating |
alloy composition |
AlZnMg or galvanized AlMg |
||
Total Weight of Plating Both Sides (Outside/Inside) |
150g/ (75/75 or 85/65) |
|||
Neutral salt spray test |
The surface of the board (without passivation, anti-fingerprint and other treatments on the surface) has a neutral salt spray test of more than or equal to 2500 hours, and there is no red rust on the surface. |
Shandong Anli Metal Co., Ltd. is a leading comprehensive enterprise integrating various metal products. Our portfolio includes hot-rolled steel coils, cold-rolled steel coils, galvanized steel coils, color-coated steel coils, steel sections, steel pipes, heat exchange pipes, automobile exhaust pipes, anchor rods, steel wires, and metal mesh. Additionally, we offer stainless steel, aluminum, copper, and metal raw materials such as billets, aluminum ingots, zinc ingots, magnesium ingots, and lead ingots.
With five production and sales bases strategically located in Binzhou, Liaocheng, Wuxi, Tianjin, Jinan, and Tai'an, we boast over 100 production lines. Our group company has imported the most advanced technology from Germany, Japan, Belgium, the United States, and the United Kingdom for iron-smelting and steel processing. Equipped with a complete automatic system, we have become one of the largest and most advanced professional manufacturers in China.
We possess four nationally recognized laboratories, two technical engineering centers, and five corporate technology centers, ensuring the highest quality standards. Our products are exported to more than 50 countries and regions worldwide, including North America, South America, Europe, the Middle East, Russia, Africa, and others.
Company Philosophy:
• Quality First: We adhere strictly to production standards during production and inspection.
• Price Advantage: We offer discounts based on real market prices.
• Transaction Security: Customer funds are always protected.
• After-Sales Guarantee: We treat customer problems as our own.
• Long-Term Cooperation: Our quality assurance, price advantage, and sincere service ensure lasting partnerships.
Shandong Anli Metal, with quality as the foundation and technology as the leader, sincerely invites friends from all walks of life to join us creating a brilliant chapter in the metal manufacturing industry!
