Expansion Joint Fabrics and Materials
Product Spotlights
Thermax Expansion Joint Fabrics & materials deliver excellent high-temperature resistance, thermal stability, flexibility and sealing performance. Durable, corrosion-resistant and customizable for reliable industrial expansion joint solutions.
US$ 2 - 60
MOQ: 100 Square Meters
Key Specifications
Get Latest Price
Technique:
Other, Woven fabrics and needle mats
Fiberglass Type:
E-Glass
Transport Package:
in rolls
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
14 days
Related Products
-
Fire and Smoke Curtain FabricsUS$ 2 - 10MOQ: 100 Square Meters -
Welding Habitat Panel FabricsUS$ 2 - 10MOQ: 100 Square Meters
-
Liquid Silicone Rubber Coated Fiberglass FabricUS$ 2 - 10MOQ: 500 Square Meters
-
Thermal Insulation Blanket MaterialsUS$ 2 - 20MOQ: 100 Square Meters
-
Thermal Insulation Blanket for ExtrusionUS$ 100 - 300MOQ: 2 Pieces
Technique
Other, Woven fabrics and needle mats
Fiberglass Type
E-Glass
Transport Package
in rolls
Specification
as requested
Origin
China
Product Parameters:
| Temperature | Materials | Advantages | Pressure | Chemical Resistance | Product Description | Applications |
| Low Ambient – 120°C (Ambient – 250°F) |
EPDM Coated Fiberglass Fluoro Rubber Coated Fiberglass |
High tensile strength, Ozone and weathering resistance |
Medium | High | 1.2mm, 1.5mm, 1.8mm 1.1mm, 1.5mm |
Hot and Cold Water, Low-Pressure Steam, Neutral Solutions Low-Pressure Steam Neutral Solutions |
| Medium 120 – 260°C (250 – 500°F) |
Silicone Coated Fiberglass | Resistant to deterioration by weathering and engine oil remains | Low | High | 0.6mm-3mm | Gaskets or Seals Recirculation Air Air Intake |
| High 260 – 550°C (500 – 1000°F) |
PTFE Coated Fiberglass PTFE Laminated |
High tear/crease resistant Smooth, low friction, non-stick surface, high tensile strength |
Low | Medium | Fabric: 0.85, 1.0mm Laminate: 0.95mm, 1.0mm, 1.2mm |
Exhaust Ventilation Fume Protection Gaskets or Seals |
| Silica Fabric | High abrasion resistance Won’t rot or mildew |
Low | Low | 0.4mm, 0.6mm, 1.0mm | Boiler Exhaust | |
| High 550 – 1000°F (1000 – 1800°F) |
Silica / PTFE Fabric Aluminized Fiberglass Blanket Insulation |
Excellent resistance to chemicals High-temperature stability |
Low | Low | Glass/Silica Mat Bio soluble blanket |
Furnaces |
Description:
Expansion Joints are flexible connectors designed to provide stress relief and seal-in media for ducting systems throughout a wide range of applications. They can be supplied from many types of materials including low-temperature elastomers to medium and hi-temperature fabrics and fluoroplastics.
Selecting the correct material for a fabric expansion joint is important for its performance and life span. The flexible belt is a composite of multiple layers, each serving a specific function, such as a gas seal, thermal barrier, or chemical resistance layer. Thermax provides a comprehensive portfolio of material combinations tailored to diverse application’s operating temperature, chemical compatibility, pressure, and the need for abrasion resistance.
