There are two types of cold-formed steel sheet piles: non-snap-type cold-formed steel sheet piles (also known as channel plates) and bite-type cold-formed steel sheet piles (divided into L-type, S-type, U-type, and Z-type). Production process: use thinner plates (commonly used thickness 8mm ~ 14mm) in the cold bending machine for continuous rolling forming.
S270GP / S320GP Hot Rolled U Type Steel Sheet Pile for Foundation Support a reusable green and environment-friendly foundation structure material, hot-rolled U-shaped steel sheet piles are highly efficient, durable, simple, lightweight, and have an excellent cross-sectional shape that is sealed and anti-seepage. And unique advantages such as safety and environmental protection.Compared with other structures, it has a light structure, strong bearing capacity, and good earthquake resistance; strong water insulation, which can make the structure quickly stop water or plug leaks, impervious to penetration and easy to construct.
Cold-formed steel sheet piles and hot-rolled steel sheet piles can be produced in U-shape, Z-shape, and W-shape. The manufacturing process is different. The wall thickness of cold-formed steel sheet piles is the same, and the thickness of hot-rolled steel sheet piles is different in different parts. do thick.
The length of hot-rolled steel sheet piles is generally limited, mainly 9 meters, 12 meters, 15 meters, 18 meters, 400 wide, and 600 wide. The water stop effect is generally better than that of cold bending, and the market stock is large.
Type |
Width |
Height |
Thickness |
Sectional area |
Weight per pile |
Weight per wall |
Moment of Inertia |
Modulus of section |
mm |
mm |
mm |
Cm2/m |
Kg/m |
Kg/ m2 |
Cm4/m |
Cm3/m |
|
ZDU7 |
750 |
320 |
5 |
71.3 |
42 |
56 |
10725 |
670 |
ZDU8 |
750 |
320 |
6 |
86.7 |
51 |
68.1 |
13169 |
823 |
ZDU9 |
750 |
320 |
7 |
101.4 |
59.7 |
79.6 |
15251 |
953 |
ZDU10-450 |
450 |
360 |
8 |
148.6 |
52.5 |
116.7 |
18268 |
1015 |
ZDU11-450 |
450 |
360 |
9 |
165.9 |
58.6 |
130.2 |
20375 |
1132 |
ZDU12-450 |
450 |
360 |
10 |
182.9 |
64.7 |
143.8 |
22444 |
1247 |
ZDU11-575 |
575 |
360 |
8 |
133.8 |
60.4 |
105.1 |
19685 |
1094 |
ZDU12-575 |
575 |
360 |
9 |
149.5 |
67.5 |
117.4 |
21973 |
1221 |
ZDU13-575 |
575 |
360 |
10 |
165 |
74.5 |
129.5 |
24224 |
1346 |
ZDU11-600 |
600 |
360 |
8 |
131.4 |
61.9 |
103.2 |
19897 |
1105 |
ZDU12-600 |
600 |
360 |
9 |
147.3 |
69.5 |
115.8 |
22213 |
1234 |
ZDU13-600 |
600 |
360 |
10 |
162.4 |
76.5 |
127.5 |
24491 |
1361 |
ZDU18- 600 |
600 |
350 |
12 |
220.3 |
103.8 |
172.9 |
32797 |
1874 |
ZDU20- 600 |
600 |
350 |
13 |
238.5 |
112.3 |
187.2 |
35224 |
2013 |
ZDU16 |
650 |
480 |
8 |
138.5 |
71.3 |
109.6 |
39864 |
1661 |
ZDU 18 |
650 |
480 |
9 |
156.1 |
79.5 |
122.3 |
44521 |
1855 |
ZDU20 |
650 |
540 |
8 |
153.7 |
78.1 |
120.2 |
56002 |
2074 |
ZDU23 |
650 |
540 |
9 |
169.4 |
87.3 |
133 |
61084 |
2318 |
ZDU26 |
650 |
540 |
10 |
187.4 |
96.2 |
146.9 |
69093 |
2559 |
ZDU30-700 |
700 |
558 |
11 |
217.1 |
119.3 |
170.5 |
83139 |
2980 |
