A36 Q235 Q345B Carbon Structural Steel Angel Bar also known as angle iron, is a long strip of steel with two sides perpendicular to each other. There are equilateral angle steel and unequal angle steel. The width of both sides of the equilateral angle steel is equal. Its specifications are expressed in millimeters of side width × side width × side thickness.
Angle steel can be used to form various stress-bearing components according to different structures, and can also be used as connectors between components. It is widely used in various building structures and engineering structures, such as house beams, bridges, transmission towers, and lifting and transportation machinery. , ships, industrial furnaces, reaction towers, container racks, cable trench brackets, power piping, busbar bracket installation, and warehouse shelves, etc. Angle steel is carbon structural steel for construction. It is a simple cross-section steel material, mainly used for metal components and factory buildings. framework etc. It requires good weldability, plastic deformation performance and certain mechanical strength during use. The raw material billet for angle steel production is low carbon square steel billet, and the finished angle steel is delivered in a hot-rolled, normalized or hot-rolled state.
Brief introduction of angle steel: Angle steel can be composed of various stress components according to different needs of the structure, and can also be used as a connector between components. Widely used in various building structures and engineering structures, such as beams, bridges, transmission towers, lifting and transportation machinery, ships, industrial furnaces, reaction towers, container racks, cable trench supports, power piping, busbar support installation, and warehouses shelves etc.
Types of angle steel: mainly divided into two types: equilateral angle steel and unequal side angle steel, among which unequal side angle steel can be divided into two types: unequal sides and equal thickness and unequal sides and unequal thickness.
| Wing width | wing | radius | CSA | Theoretical Weight | y0 | Ix | MAX | MIN | ix | iu | iv |
| b | t | R | (cm2) | kg/m | (cm) | cm4 | cm3 | cm | cm | cm | |
| 20 | 3 | 3.5 | 1.13 | 0.89 | 0.60 | 0.40 | 0.66 | 0.29 | 0.59 | 0.75 | 0.39 |
| 20 | 4 | 1.46 | 1.15 | 0.64 | 0.50 | 0.78 | 0.36 | 0.58 | 0.73 | 0.38 | |
| 25 | 3 | 3.5 | 1.43 | 1.12 | 0.73 | 0.82 | 1.12 | 0.46 | 0.76 | 0.95 | 0.49 |
| 25 | 4 | 1.86 | 1.46 | 0.76 | 1.03 | 1.34 | 0.59 | 0.74 | 0.93 | 0.48 | |
| 30 | 3 | 4.5 | 1.75 | 1.37 | 2.85 | 1.46 | 1.72 | 0.68 | 0.91 | 1.15 | 0.59 |
| 30 | 4 | 2.28 | 1.79 | 0.89 | 1.84 | 2.08 | 0.87 | 0.90 | 1.13 | 0.58 | |
| 36 | 3 | 4.5 | 2.11 | 1.66 | 1.00 | 2.58 | 2.59 | 0.99 | 1.11 | 1.39 | 0.71 |
| 36 | 4 | 2.76 | 2.16 | 1.04 | 3.29 | 3.18 | 1.28 | 1.09 | 1.38 | 0.70 | |
| 36 | 5 | 3.38 | 2.65 | 1.07 | 3.95 | 3.68 | 1.56 | 1.08 | 1.36 | 0.70 | |
| 40 | 3 | 5 | 2.36 | 1.85 | 1.09 | 3.59 | 3.28 | 1.23 | 1.23 | 1.55 | 0.79 |
| 40 | 4 | 3.09 | 2.42 | 1.13 | 4.60 | 4.05 | 1.60 | 1.22 | 1.54 | 0.79 | |
| 40 | 5 | 3.79 | 2.98 | 1.17 | 5.53 | 4.72 | 1.96 | 1.21 | 1.52 | 0.78 | |
| 45 | 3 | 5 | 2.66 | 2.09 | 1.22 | 5.17 | 4.25 | 1.58 | 1.39 | 1.76 | 0.90 |
| 45 | 4 | 3.49 | 2.74 | 1.26 | 6.65 | 5.29 | 2.05 | 1.38 | 1.74 | 0.89 | |
| 45 | 5 | 4.29 | 3.37 | 1.30 | 8.04 | 6.20 | 2.51 | 1.37 | 1.72 | 0.88 | |
| 45 | 6 | 5.08 | 3.99 | 1.33 | 9.33 | 6.99 | 2.95 | 1.36 | 1.71 | 0.88 |
Contact us for more detailed angle steel parameter information
