China Wholesale Q235B Q345 Q345b S275 S355 Hot Rolled Steel Sheet Pile Steel Profile for CofferdamUS$ 510 - 535MOQ: 10 Tons -
Cold Rolled U Steel Sheet PileUS$ 510 - 535MOQ: 10 Tons
-
400mm 20m 400*100*10.5 Used U Type Cold Rolled Carbon Steel Sheet Pile Z for ConstructionUS$ 510 - 535MOQ: 10 Tons
-
Larssen Z Type Quay Construction Sheet Piling U Type Steel Sheet Pile for Welding and CuttingUS$ 510 - 535MOQ: 10 Tons
-
Hot Sale Steel Sheet Piles 400*150*13mm 400*170*15.5mm Type 3 Type 4 U Shape Steel Sheet Pile Wall for BuildingUS$ 510 - 535MOQ: 10 Tons
There are two types of cold-formed steel sheet piles: non-snap-type cold-formed steel sheet piles (also known as channel plates) and bite-type cold-formed steel sheet piles (divided into L-type, S-type, U-type, and Z-type). Production process: use thinner plates (commonly used thickness 8mm ~ 14mm) in the cold bending machine for continuous rolling forming.
S270GP / S320GP Hot Rolled U Type Steel Sheet Pile for Foundation Support a reusable green and environment-friendly foundation structure material, hot-rolled U-shaped steel sheet piles are highly efficient, durable, simple, lightweight, and have an excellent cross-sectional shape that is sealed and anti-seepage. And unique advantages such as safety and environmental protection.Compared with other structures, it has a light structure, strong bearing capacity, and good earthquake resistance; strong water insulation, which can make the structure quickly stop water or plug leaks, impervious to penetration and easy to construct.
Cold-formed steel sheet piles and hot-rolled steel sheet piles can be produced in U-shape, Z-shape, and W-shape. The manufacturing process is different. The wall thickness of cold-formed steel sheet piles is the same, and the thickness of hot-rolled steel sheet piles is different in different parts. do thick.
The length of hot-rolled steel sheet piles is generally limited, mainly 9 meters, 12 meters, 15 meters, 18 meters, 400 wide, and 600 wide. The water stop effect is generally better than that of cold bending, and the market stock is large.
Type |
Width |
Height |
Thickness |
Sectional area |
Weight per pile |
Weight per wall |
Moment of Inertia |
Modulus of section |
mm |
mm |
mm |
Cm2/m |
Kg/m |
Kg/ m2 |
Cm4/m |
Cm3/m |
|
ZDU7 |
750 |
320 |
5 |
71.3 |
42 |
56 |
10725 |
670 |
ZDU8 |
750 |
320 |
6 |
86.7 |
51 |
68.1 |
13169 |
823 |
ZDU9 |
750 |
320 |
7 |
101.4 |
59.7 |
79.6 |
15251 |
953 |
ZDU10-450 |
450 |
360 |
8 |
148.6 |
52.5 |
116.7 |
18268 |
1015 |
ZDU11-450 |
450 |
360 |
9 |
165.9 |
58.6 |
130.2 |
20375 |
1132 |
ZDU12-450 |
450 |
360 |
10 |
182.9 |
64.7 |
143.8 |
22444 |
1247 |
ZDU11-575 |
575 |
360 |
8 |
133.8 |
60.4 |
105.1 |
19685 |
1094 |
ZDU12-575 |
575 |
360 |
9 |
149.5 |
67.5 |
117.4 |
21973 |
1221 |
ZDU13-575 |
575 |
360 |
10 |
165 |
74.5 |
129.5 |
24224 |
1346 |
ZDU11-600 |
600 |
360 |
8 |
131.4 |
61.9 |
103.2 |
19897 |
1105 |
ZDU12-600 |
600 |
360 |
9 |
147.3 |
69.5 |
115.8 |
22213 |
1234 |
ZDU13-600 |
600 |
360 |
10 |
162.4 |
76.5 |
127.5 |
24491 |
1361 |
ZDU18- 600 |
600 |
350 |
12 |
220.3 |
103.8 |
172.9 |
32797 |
1874 |
ZDU20- 600 |
600 |
350 |
13 |
238.5 |
112.3 |
187.2 |
35224 |
2013 |
ZDU16 |
650 |
480 |
8 |
138.5 |
71.3 |
109.6 |
39864 |
1661 |
ZDU 18 |
650 |
480 |
9 |
156.1 |
79.5 |
122.3 |
44521 |
1855 |
ZDU20 |
650 |
540 |
8 |
153.7 |
78.1 |
120.2 |
56002 |
2074 |
ZDU23 |
650 |
540 |
9 |
169.4 |
87.3 |
133 |
61084 |
2318 |
ZDU26 |
650 |
540 |
10 |
187.4 |
96.2 |
146.9 |
69093 |
2559 |
ZDU30-700 |
700 |
558 |
11 |
217.1 |
119.3 |
170.5 |
83139 |
2980 |
Shandong Anli Metal Co., Ltd. is a leading comprehensive enterprise integrating various metal products. Our portfolio includes hot-rolled steel coils, cold-rolled steel coils, galvanized steel coils, color-coated steel coils, steel sections, steel pipes, heat exchange pipes, automobile exhaust pipes, anchor rods, steel wires, and metal mesh. Additionally, we offer stainless steel, aluminum, copper, and metal raw materials such as billets, aluminum ingots, zinc ingots, magnesium ingots, and lead ingots.
With five production and sales bases strategically located in Binzhou, Liaocheng, Wuxi, Tianjin, Jinan, and Tai'an, we boast over 100 production lines. Our group company has imported the most advanced technology from Germany, Japan, Belgium, the United States, and the United Kingdom for iron-smelting and steel processing. Equipped with a complete automatic system, we have become one of the largest and most advanced professional manufacturers in China.
We possess four nationally recognized laboratories, two technical engineering centers, and five corporate technology centers, ensuring the highest quality standards. Our products are exported to more than 50 countries and regions worldwide, including North America, South America, Europe, the Middle East, Russia, Africa, and others.
Company Philosophy:
• Quality First: We adhere strictly to production standards during production and inspection.
• Price Advantage: We offer discounts based on real market prices.
• Transaction Security: Customer funds are always protected.
• After-Sales Guarantee: We treat customer problems as our own.
• Long-Term Cooperation: Our quality assurance, price advantage, and sincere service ensure lasting partnerships.
Shandong Anli Metal, with quality as the foundation and technology as the leader, sincerely invites friends from all walks of life to join us creating a brilliant chapter in the metal manufacturing industry!
