Help CenterDelphi Common Rail Fuel Injection Pump Camring 7180-971B-131B
Product Spotlights
Related Products
-
CAV DPA Diesel Rotary Injection Pump Camring 7174-67CZNegotiableMOQ: 100 Pieces -
Fuel Injection Kit Cam Ring & Scroll Plate 7167-975ENegotiableMOQ: 100 Pieces
-
DPA Diesel Rotary Injection Pump Cam Ring 7139-940ENegotiableMOQ: 100 Pieces
-
Top Quality Diesel Injection System Parts Camring 28369010 for CAV 9521A030HNegotiableMOQ: 100 Pieces
-
Rotary Injection Pump Cam Ring And Scroll Plate 7189-100EDNegotiableMOQ: 100 Pieces
Delphi Common Rail Fuel Injection Pump Camring 7180-971B-131B for DELPHI-Lucas CAV 1405/1487 engines
Tina Chen - Bombas de Inyeccion Diesel
Wha/tsa/pp:+86-133/869/01379
tina at china-lutong dot net
Distributor Fuel Injection Pumps - DPA (Lucas) Type. This pump uses a single steel rotor, which works as the pumping element and also distributes the fuel. The rotor rotates in a stationary steel cylindrical sleeve known as the hydraulic head.
The pumping section of the rotor is flanged and has a larger diameter than the distributor section. It has a transverse cylinder bore to house two opposed pumping plungers. A stationary internal-cam ring is installed in the pump housing and operates the plungers through rollers and shoes, which are placed in slots machined into the circumference of the rotor flange. The cam ring uses as many lobes as there are engine cylinders, and they are evenly placed round the ring. The outward movement of the opposed plungers is controlled by metered fuel pressure.
| Cam Ring | 7189-100ED | |
| Cam Ring | 7174-67CF | |
| Cam Ring | 7123-308N | |
| Cam Ring | 7180-970B | |
| Cam Ring | 7123-308E | |
| Cam Ring | 7123-309D | |
| Cam Ring | 7189-100CE=7189-100AA | |
| Cam Ring | 7189-100DC | |
| Cam Ring | 7174-67AT | |
| Cam Ring | 7139-974D | |
| Cam Ring | 7174-067EJ | |
| Cam Ring | 7189-100CK | |
| Cam Ring | 7189-100BL | |
| Cam Ring | 7189-100CA | |
| Cam Ring | 7189-100DE | |
| Cam Ring | 7189-100CW | |
| Cam Ring | 7139-308e | |
| Cam Ring | 7189-100BQ | |
| Cam Ring | 7123-309M | |
| Cam Ring | 7123-309Q | |
| Cam Ring | 7123-309E | |
| Cam Ring | 7139-841C | |
| Cam Ring | 7139-940Q | |
| Cam Ring | 7123-308D | |
| Cam Ring | 7123-308AA | |
| Cam Ring | 7123-308T | |
| Cam Ring | 7123-308F | |
| Cam Ring | 7167-976D | |
| Cam Ring | 7167-976U |
