Home > Metallurgy, Mineral & Energy > Steel & Products > Steel H Beam > Price of H-beams per Ton (Ipn, China Ipe, H-beams) per Kilogram

Price of H-beams per Ton (Ipn, China Ipe, H-beams) per Kilogram

Price of H-beams per Ton (Ipn, China Ipe, H-beams) per Kilogram thumbnail-2

Price of H-beams per Ton (Ipn, China Ipe, H-beams) per Kilogram thumbnail-3

Price of H-beams per Ton (Ipn, China Ipe, H-beams) per Kilogram thumbnail-4

Price of H-beams per Ton (Ipn, China Ipe, H-beams) per Kilogram thumbnail-5

Price of H-beams per Ton (Ipn, China Ipe, H-beams) per Kilogram photo-1

Price of H-beams per Ton (Ipn, China Ipe, H-beams) per Kilogram photo-2

Price of H-beams per Ton (Ipn, China Ipe, H-beams) per Kilogram photo-3

Price of H-beams per Ton (Ipn, China Ipe, H-beams) per Kilogram photo-4

Price of H-beams per Ton (Ipn, China Ipe, H-beams) per Kilogram photo-5

Product Spotlights

H-beams are commonly used in steel structures. Chinese national standard grades are typically Q235 and Q345, but European standard materials such as S275JR, S345JR, and S355JR can also be provided. The most common American grades are ASTM A36, etc...

US$ 620 10 - 27 Tons

US$ 580 ≥28 Tons

Key Specifications

Get Latest Price

Certification:

IS0, ROHS, ABS

Grade:

SS355JR

Standard:

AISI, JIS, ASTM, DIN, BS, GB

Contact Supplier Request Quote Chat Now

Shandong Anli Materials Co., Ltd.

1Yr

Payment & Shipping

Payment Methods:

Port of Shipment:

Any port

Delivery Detail:

5 days

Product Details
Company Profile
Contact Us

Certification IS0, ROHS, ABS

Grade SS355JR

Standard AISI, JIS, ASTM, DIN, BS, GB

Steel Grade S235JR/J0/J2, S275JR/J0/J2, S355JR/J0/J2

Transport Package Water proof

Specification IPE/IPN

Trademark ANLI

Origin CHNIA

H-beams are commonly used in steel structures. The national standard grades are generally Q235 and Q345, specifically grades B, C, and D. Grade E is used in colder northern regions, but this is extremely rare. The most common Japanese grades are SS400, SM490A/B, and SN490A/B. European standards commonly use S235 and S355, specifically grades JR, J0, and J2.

H-shaped steel is a high-efficiency profile with a more optimized cross-sectional area distribution and a more reasonable strength-to-weight ratio. Since all parts of the H-shaped steel are arranged at right angles, the H-shaped steel has the advantages of strong bending resistance in all directions, simple construction, cost saving and light structural weight, and has been widely used.
ASTM standard American standard H-beam has three main quality grades: A36, A572, A992, etc. A36 material and A572 material represent carbon structural steel, and A992 is low alloy steel.
European standard section steel UB series - British standard H section steel, used in various steel structure buildings, marine engineering, energy. Available in European standard angle steel, European standard channel steel, European standard H-beam, also used in the overall structure construction of offshore oil platforms, LNG, refinery and other modular steel structures.
1. Specification implementation standard:
BS EN 10365-2017 replaces the old standard EN10034-1993
2. Material implementation standard:
Material: S235JR/J0/J2, S275JR/J0/J2, S355JR/J0/J2/K2, S450J0

Size	G(kg/m)	h	b	tw	tf	r	A	hi	d	Ø	pmin
IPE 80 A•/*	5,0	78	46	3,3	4,2	5	6,38	69,6	59,6	-	-
IPE 80*	6,0	80	46	3,8	5,2	5	7,64	69,6	59,6	-	-
IPE A 100•/*	6,9	98	55	3,6	4,7	7	8,78	88,6	74,6	-	-
IPE 100*	8,1	100	55	4,1	5,7	7	10,3	88,6	74,6	-	-
IPE O 220+	29,4	222	112	6,6	10,2	12	37,4	201,6	177,6	M 10	58
IPE A 240•	26,2	237	120	5,2	8,3	15	33,3	220,4	190,4	M 12	64
IPE 240	30,7	240	120	6,2	9,8	15	39,1	220,4	190,4	M 12	66
IPE O 240+	34,3	242	122	7	10,8	15	43,7	220,4	190,4	M 12	66
IPE A 270•	30,7	267	135	5,5	8,7	15	39,2	249,6	219,6	M 16	70
IPE 270	36,1	270	135	6,6	10,2	15	45,9	249,6	219,6	M 16	72
IPE O 270+	42,3	274	136	7,5	12,2	15	53,8	249,6	219,6	M 16	72
IPE O 330+	57,0	334	162	8,5	13,5	18	72,6	307	271	M 16	80
IPE A 360•	50,2	357,6	170	6,6	11,5	18	64,0	334,6	298,6	M 22	86
IPE 360	57,1	360	170	8	12,7	18	72,7	334,6	298,6	M 22	88
IPE O 360+	66,0	364	172	9,2	14,7	18	84,1	334,6	298,6	M 22	90
IPE A 400•	57,4	397	180	7	12	21	73,1	373	331	M 22	94
IPE 750 x 196+	196	770	268	15,6	25,4	17	251	719,2	685,2	M 27	106
IPN 80*	5,9	80	42	3,9	5,9	3,9	2,3	7,58	59	-	-
IPN 240*	36,2	240	106	8,7	13,1	8,7	5,2	46,1	192,5	M 10	54
IPN 260*	41,9	260	113	9,4	14,1	9,4	5,6	53,3	208,9	M 12	62
IPN 280*	47,9	280	119	10,1	15,2	10,1	6,1	61,0	225,1	M 12	68
IPN 300*	54,2	300	125	10,8	16,2	10,8	6,5	69,0	241,6	M 12	70
IPN 320*	61,0	320	131	11,5	17,3	11,5	6,9	77,7	257,9	M 12	70
IPN 340*	68,0	340	137	12,2	18,3	12,2	7,3	86,7	274,3	M 12	78
IPN 360*	76,1	360	143	13	19,5	13	7,8	97,0	290,2	M 12	78
IPN 450*	115	450	170	16,2	24,3	16,2	9,7	147	363,6	M 16	92
IPN 600*	199	600	215	21,6	32,4	21,6	13	254	485,8	M 24	126

Shandong Anli Metal Co., Ltd. is a leading comprehensive enterprise integrating various metal products. Our portfolio includes hot-rolled steel coils, cold-rolled steel coils, galvanized steel coils, color-coated steel coils, steel sections, steel pipes, heat exchange pipes, automobile exhaust pipes, anchor rods, steel wires, and metal mesh. Additionally, we offer stainless steel, aluminum, copper, and metal raw materials such as billets, aluminum ingots, zinc ingots, magnesium ingots, and lead ingots.

With five production and sales bases strategically located in Binzhou, Liaocheng, Wuxi, Tianjin, Jinan, and Tai'an, we boast over 100 production lines. Our group company has imported the most advanced technology from Germany, Japan, Belgium, the United States, and the United Kingdom for iron-smelting and steel processing. Equipped with a complete automatic system, we have become one of the largest and most advanced professional manufacturers in China.

We possess four nationally recognized laboratories, two technical engineering centers, and five corporate technology centers, ensuring the highest quality standards. Our products are exported to more than 50 countries and regions worldwide, including North America, South America, Europe, the Middle East, Russia, Africa, and others.

Company Philosophy:

• Quality First: We adhere strictly to production standards during production and inspection.

• Price Advantage: We offer discounts based on real market prices.

• Transaction Security: Customer funds are always protected.

• After-Sales Guarantee: We treat customer problems as our own.

• Long-Term Cooperation: Our quality assurance, price advantage, and sincere service ensure lasting partnerships.

Shandong Anli Metal, with quality as the foundation and technology as the leader, sincerely invites friends from all walks of life to join us creating a brilliant chapter in the metal manufacturing industry!

Product Tags: IPE H-Beams , Q355BJR H-Beams , Q235BJR H-Beams
