ECO IP65 110V Hybrid Iverter：SW 3K5SH/LV
3.5Kw Eco Hybrid inverter,2MPPT,Battery 48Vdc. 110Vac,IP65 Within Wifi&CT, Touch LCD,9pcs parallel
Features:
• Fit for 110 V/120 V/127 V grid voltages
• IP65 indoor or outdoor installation
• Support 40 V-60 V lithium-ion and lead-acid battery system
• Built in Wi-Fi , remote App monitoring and updating
•
• 2 MPPTs , 18 A+18 A PV input current for high power solar panels
• 200% PV oversizing, 7,800 W Max. PV usable power
• 90 V lower startup voltage , 70 V-480 V wide MPPT voltage range
• 75 A Max. battery charge/discharge current
• 41 A Max. grid passthrough current
• Support generator/smart load/AC coupling
•
• 6 time periods for battery charging/discharging
• Support split-phase and 3-phase system operation
Efficiency
Max. Efficiency 97.3%
Input (PV)
Max. PV Usable Power 7,800W
Max. PV Voltage 500V
Start-up Voltage 90V
MPPT Voltage Range 70V-480V
Max. Input Current Per MPPT 18A/18A
Max. Short Circuit Current Per MPPT 25A/25A
String Per MPPT 1/1
Nos. of MPPT 2
Input/Output (BAT)
Battery Type Lithium-ion/Lead-acid
Nominal Battery Voltage 48V
Battery Voltage Range 40V-60V
Max. Charging/Discharging Current 75A/75A
Input/Output (Grid)
Nominal AC Output Power 3,157W @110V, 3,444W @120V, 3,645W @127V
Max. AC Output Current 28.7A
Max. Input Current From Grid 41A
Max. Grid Passthrough Current 41A
Rated Grid Voltage 110V/120V/127V, L+N+PE
Rated Grid Frequency 50Hz/60Hz
Power Factor > 0.99 @rated power (Adjustable 0.8 LD - 0.8 LG)
THDI
Output (Back up)
Nominal Output Power 3,157W @110V, 3,444W @120V, 3,645W @127V
Max. AC Output Current 28.7A
Peak Output Power 200%, 10s
Nominal Output Voltage 110V/120V/127V, L+N+PE
Nominal Output Frequency 50Hz/60Hz
Transfer Time
THDV
Protection
Protection Category Class I
PV Switch Optional
Anti-islanding Protection Yes
AC Over Current Protection Yes
PV/AC Over Voltage Protection Yes
AC Short Circuit Protection Yes
PV Reverse Protection Yes
Surge Arrester Type III
General
Max. Operation Altitude 4000m (>2000m derating)
Protection Degree IP65
Operating Temperature Range -25℃~60℃(>45℃ derating)
Relative Humidity 0~100%
Cooling Natural Cooling
Mounting Wall bracket
Dimensions (W*H*D) 367mm*421mm*215mm
Weight 15kg
HMI & COM
Display LED+LCD
Communication CAN (for BMS), RS485, CAN (for parallel), 1*DO, 1*DI, Wi-Fi
Certification
Safety EN 62109-1/2
EMC EN 61000-6-1/2/3/4
Warranty 5 Years
