Color steel coil(PPGI) & PPGL are pre-coated galvanized steel coils, also known as pre-coated steel coils, color-coated steel coils, etc. PPGI & PPGL are made of hot-dip galvanized steel coils as the substrate, which are first surface pre-treated, then coated with one or more layers of liquid coating by roller coating, and finally baked and cooled. The coatings used include polyester, silicon-modified polyester, high durability, corrosion resistance, formability, etc. Our PPGI & PPGL (pre-coated galvanized steel) and PPGL (pre-coated galvanized steel) are available in a variety of specifications. We can also provide products with a service life of up to decades according to customer requirements. Color-coated steel coils/sheets (PPGI & PPGL) are widely used in:Construction, roofing, transportation, solar energy, home appliances, such as refrigerator side door panels, DVD shells, air conditioners, washing machines and other color-coated steel coils.
All RAL Colors RAL1013 RAL 1015 RAL 2002 RAL 2005 RAL 3005 RAL 3013 RAL 5010 RAL 5012 RAL 5015 RAL 5017 RAL 6005 RAL7011 etc.PPGI is a galvanized coil that is coated with color coatings using a certain technology to give the product more colors. This rich and beautiful surface makes it more versatile in use.
For the use of color steel coils, we have to choose different types of color steel coils to manufacture different PPGI. Speaking of this, I have to briefly introduce the types of color steel coils, which are divided into five categories. That is, home appliances, optical materials, decorative materials, building materials, and packaging. Among them, the production process of color steel coils for home appliances is the most delicate and perfect.
Location |
category |
value |
||
Executive standard |
National standard |
GB/T12754-2019 |
||
American Standard/European Standard |
ASTM A792M |
|||
Cold rolled substrate |
Width specification |
Cold rolled substrate thickness |
Including metallized layer, the thickness after painting |
Label thickness |
1200mm |
≥0.41mm |
≥0.46mm |
≥0.45mm |
|
Size deviation |
Width tolerance |
Upper deviation +4mm |
||
Lower deviation 0 |
||||
thickness |
Upper deviation +0.05mm |
|||
Lower deviation 0 |
||||
Yield Strength |
>300MPA |
|||
tensile strength |
270-500MPA |
|||
elongation after break |
More than 20% |
|||
Steel coil inner diameter |
Standard: 508mm,Except for other agreements |
|||
metal coating |
alloy composition |
AlZnMg or galvanized AlMg |
||
Total Weight of Plating Both Sides (Outside/Inside) |
150g/ (75/75 or 85/65) |
|||
Neutral salt spray test |
The surface of the board (without passivation, anti-fingerprint and other treatments on the surface) has a neutral salt spray test of more than or equal to 2500 hours, and there is no red rust on the surface. |
