H-beams are commonly used in steel structures. The national standard grades are generally Q235 and Q345, specifically grades B, C, and D. Grade E is used in colder northern regions, but this is extremely rare. The most common Japanese grades are SS400, SM490A/B, and SN490A/B. European standards commonly use S235 and S355, specifically grades JR, J0, and J2.
H-shaped steel is a high-efficiency profile with a more optimized cross-sectional area distribution and a more reasonable strength-to-weight ratio. Since all parts of the H-shaped steel are arranged at right angles, the H-shaped steel has the advantages of strong bending resistance in all directions, simple construction, cost saving and light structural weight, and has been widely used.
ASTM standard American standard H-beam has three main quality grades: A36, A572, A992, etc. A36 material and A572 material represent carbon structural steel, and A992 is low alloy steel.
European standard section steel UB series - British standard H section steel, used in various steel structure buildings, marine engineering, energy. Available in European standard angle steel, European standard channel steel, European standard H-beam, also used in the overall structure construction of offshore oil platforms, LNG, refinery and other modular steel structures.
1. Specification implementation standard:
BS EN 10365-2017 replaces the old standard EN10034-1993
2. Material implementation standard:
Material: S235JR/J0/J2, S275JR/J0/J2, S355JR/J0/J2/K2, S450J0
| Size | G(kg/m) | h | b | tw | tf | r | A | hi | d | Ø | pmin |
| IPE 80 A•/* | 5,0 | 78 | 46 | 3,3 | 4,2 | 5 | 6,38 | 69,6 | 59,6 | - | - |
| IPE 80* | 6,0 | 80 | 46 | 3,8 | 5,2 | 5 | 7,64 | 69,6 | 59,6 | - | - |
| IPE A 100•/* | 6,9 | 98 | 55 | 3,6 | 4,7 | 7 | 8,78 | 88,6 | 74,6 | - | - |
| IPE 100* | 8,1 | 100 | 55 | 4,1 | 5,7 | 7 | 10,3 | 88,6 | 74,6 | - | - |
| IPE O 220+ | 29,4 | 222 | 112 | 6,6 | 10,2 | 12 | 37,4 | 201,6 | 177,6 | M 10 | 58 |
| IPE A 240• | 26,2 | 237 | 120 | 5,2 | 8,3 | 15 | 33,3 | 220,4 | 190,4 | M 12 | 64 |
| IPE 240 | 30,7 | 240 | 120 | 6,2 | 9,8 | 15 | 39,1 | 220,4 | 190,4 | M 12 | 66 |
| IPE O 240+ | 34,3 | 242 | 122 | 7 | 10,8 | 15 | 43,7 | 220,4 | 190,4 | M 12 | 66 |
| IPE A 270• | 30,7 | 267 | 135 | 5,5 | 8,7 | 15 | 39,2 | 249,6 | 219,6 | M 16 | 70 |
| IPE 270 | 36,1 | 270 | 135 | 6,6 | 10,2 | 15 | 45,9 | 249,6 | 219,6 | M 16 | 72 |
| IPE O 270+ | 42,3 | 274 | 136 | 7,5 | 12,2 | 15 | 53,8 | 249,6 | 219,6 | M 16 | 72 |
| IPE O 330+ | 57,0 | 334 | 162 | 8,5 | 13,5 | 18 | 72,6 | 307 | 271 | M 16 | 80 |
| IPE A 360• | 50,2 | 357,6 | 170 | 6,6 | 11,5 | 18 | 64,0 | 334,6 | 298,6 | M 22 | 86 |
| IPE 360 | 57,1 | 360 | 170 | 8 | 12,7 | 18 | 72,7 | 334,6 | 298,6 | M 22 | 88 |
| IPE O 360+ | 66,0 | 364 | 172 | 9,2 | 14,7 | 18 | 84,1 | 334,6 | 298,6 | M 22 | 90 |
| IPE A 400• | 57,4 | 397 | 180 | 7 | 12 | 21 | 73,1 | 373 | 331 | M 22 | 94 |
| IPE 750 x 196+ | 196 | 770 | 268 | 15,6 | 25,4 | 17 | 251 | 719,2 | 685,2 | M 27 | 106 |
| IPN 80* | 5,9 | 80 | 42 | 3,9 | 5,9 | 3,9 | 2,3 | 7,58 | 59 | - | - |
| IPN 240* | 36,2 | 240 | 106 | 8,7 | 13,1 | 8,7 | 5,2 | 46,1 | 192,5 | M 10 | 54 |
| IPN 260* | 41,9 | 260 | 113 | 9,4 | 14,1 | 9,4 | 5,6 | 53,3 | 208,9 | M 12 | 62 |
| IPN 280* | 47,9 | 280 | 119 | 10,1 | 15,2 | 10,1 | 6,1 | 61,0 | 225,1 | M 12 | 68 |
| IPN 300* | 54,2 | 300 | 125 | 10,8 | 16,2 | 10,8 | 6,5 | 69,0 | 241,6 | M 12 | 70 |
| IPN 320* | 61,0 | 320 | 131 | 11,5 | 17,3 | 11,5 | 6,9 | 77,7 | 257,9 | M 12 | 70 |
| IPN 340* | 68,0 | 340 | 137 | 12,2 | 18,3 | 12,2 | 7,3 | 86,7 | 274,3 | M 12 | 78 |
| IPN 360* | 76,1 | 360 | 143 | 13 | 19,5 | 13 | 7,8 | 97,0 | 290,2 | M 12 | 78 |
| IPN 450* | 115 | 450 | 170 | 16,2 | 24,3 | 16,2 | 9,7 | 147 | 363,6 | M 16 | 92 |
| IPN 600* | 199 | 600 | 215 | 21,6 | 32,4 | 21,6 | 13 | 254 | 485,8 | M 24 | 126 |
