PD464T Dual-Spectrum Speed Dome Camera
The robust PD4 series Dual-Spectrum Speed Dome Camera features a 640×512 resolution and a 50mm electrically adjustable lens. It integrates with a 37× optical zoom visible light camera and a rapid-rotation dome camera for fast monitoring across medium to long ranges.
The front end is equipped with intelligent analysis algorithms for classifying and recognizing target objects.
The SD4 series can be widely used in intelligent security and fire protection scenarios such as forest fire prevention, river monitoring, construction site perimeter security, and electrical power temperature measurement.
Feature
12μm Uncooled Infrared Detector
Adopting the latest 12μm uncooled infrared detectors, integrated with advanced infrared imaging algorithms for better image quality.
Dual-Spectrum Imaging
All-weather, 24/7 security monitoring with dual thermal&visible light imaging.
Accurate Temperature Measurement
Measurement range from -20°C to 550°C, accuracy ±2°C or 2%.
Long-Range Observation
Supports a 50mm motorized lens for detecting fire points up to 3km away and individuals up to 1km away.
AI Target Recognition
Smart video content analysis, human/vehicle recognition on thermal channel for crossline/intrusion detection.
Platform Integration
Support ONVIF, provide SDK&demo for development; provide NVR and VMS software for application.
|
|
Specification
| Thermal Module | |
|---|---|
| Detector TypeVOx, uncooled FPA detectorsSpectral Range8~14μmNETD≤40mK(@25°C,F#1.0,25Hz)Resolution640×512Pixel Pitch12μmFocal Length9.1mm/13mm/25mm/50mm Athermalized/Motorized lens | |
| Optical Module | |
| Sensor4MP 1/1.8" Progressive Scan CMOSResolution2560×1920Focal Length6.5~240mm, 37xIR distance200m | |
| Image Function | |
| Bi-Spectrum Image FusionSupport | |
| PTZ | |
| Pan360° continuous，0.1°~200°/sTilt-27°~+90°，0.1°~120°/sPreset1024Scan modePreset/Pattern Scan/Patrol Scan/ Linear Scan/Panorama ScanWiperAuto-wiper | |
| Temperature Measurement | |
| Temperature Range-20℃~+550℃Temperature Accuracy±2℃ or ±2%Temperature MeasurementSuport 4 temperature measure ment rules(fullframe, point, line, area) | |
| Smart Function | |
| Fire DetectionSupportVCASupport Line Crossing&Intrusion detection with AI human/Vehicle recognition2-Way AudioSupportLinkage ActionVideo/ Snapshot/Email/Alarm output | |
| System Interface | |
| PowerDC 24V±25%Network1 RJ45 10M / 100M self-adaptive Ethernet portAudio1 in/1 outAlarm7 in/2 outStorageMicro SD memory（maximum 256G）ResetSupportSerial Port1 channel RS485, can support Pelco protocol | |
| General | |
| Work Environment-40℃~+70℃； | |
Application Scenarios
