1000 ºC Calcium silicate thermal insulation boards are composed mainly of SiO2, CaO and a little of fiber . It is made by pressing and moulding after chemical reaction under high temperature.
The boards are mainly used in industrial furnaces of steel, electrolytic aluminium, cement, glass, ceramic and so on for refractory and thermal insulation. The products are also used in petrochemistry, building, fireplace, ventilation duct, etc. for fireproof and thermal insulation.
It can be used under 1000ºC high temperature without deformation, fracture and powdering. It is 100% non-asbestos.
Our company is the largest manufactory of 1000 º C calcium silicate thermal insulation boards in China, yearly production up to 70, 000 cubic meters. Since 1989 we have begun to produce this kind of boards, which have acquired certificate of ISO 9001 in 2007.
| High density calcium silicate board index | |||
| Items | Unit | KRS Standard TYPE | |
| N17 | N14 | ||
| Glass fiber reinforced | Carbon fiber reinforced | ||
| Bulk density | kg/m3 | 850(±10%) | 1000-1300(±10%) |
| Temp.Limit | °C | 1000-1100 | 1100-1200 |
| Flexural Strength | Mpa | 6.5 | 15 |
| Compressive Strength | Mpa | 15.5 | 23 |
| Thermal Cond | W/m.k | 7*10-6 | 7*10-6 |
| Thermal shrinkage after 16 hours | % | 1000°C ≤1.0 | 1000°C ≤0.90 |
Product packaging:
cartons+wooden pallet or as per customer's request. The neutral carton packing or OEM.
Lead time and payment terms:
The order will be shipped within 15 days after confirmation
Terms of payment: T/T, 30% deposit, the remaining 70% will be paid before shipment.
The main products of the company are high temperature resistant calcium silicate heat insulation products, ceramic fiber products,perlite product ,refractory brick,rock wool and other thermal insulation refractory materials.
Products are widely used in the construction of urban heat network and the heat insulation of various kinds of kiln and pipeline in metallurgy, petroleum, chemical, cement, electronics, machinery, ceramics, glass, natural gas and other industries.
Other specifications can be customized according to customer requirements.
Water repellent products can be customized.
