Factory Direct Sales F7364 Flange 10K Gate Valve JIS Daily Standard Marine Gate Valve Manual Cast Iron Marine Gate Valve
US$ 689.66
≥1 Set
Key Specifications
Get Latest Price
Type:
GATE VALVES
application:
General
media:
Water
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CF8 Stainless Steel Pneumatic Slide Knife Gate Valve Actuator Manual Power for High Temperature Water and Oil Angle StructureUS$ 689.66MOQ: 1 Set -
ANSI Ductile Iron Gate Valve Metal Seat Flanged Cast Iron Gate Valve 4 -inch Gate Valve PriceUS$ 689.66MOQ: 1 Set
-
DIN/EN Electric Motorized Gate Valve WCB Cast Steel Flange Resilient Seat Electric With Actuator DN1200 Large Diameter SizeUS$ 688.98 - 689.66MOQ: 1 Piece
-
ANSI GB DIN JIS Gate Valve Z41X-16Q/Z41X-10Q PN10 PN16 DN50 DN100 Water Resilient/Metal Seated Seal With Handwheel Rising StemUS$ 124.07 - 124.14MOQ: 1 Piece
-
DIN Resilient Gate Valve Ductile /Cast Iron WCB A216 GGG50 PN16 Metal Seat Soft Seal Flange Lifting Manual With Brass SealUS$ 68.28 - 68.97MOQ: 1 Piece
application
General
media
Water
port size
DN50-DN450
power
Manual
structure
Gate
temperature of media
Medium Temperature
model number
Z45T/H
brand name
CHX
place of origin
Hebei, China
customized support
OEM, ODM
warranty
1 years
Body
FC200
Disc
FC200
Seat
Bronze/2Cr13
Stem
2Cr13/SS304/SS316/Bronze
Color
Grey, Black
Suitable
Water,Steam,Oil
Connection Type
Flange
Drive Way
Manual
Certificate
ISO9001,ISO14001
Specification
The Main Parts and Materials: | ||
Body | FC200 | |
Stem | 2Cr13/SS304/SS316/Bronze | |
Disc | FC200 | |
Seat | Bronze/2Cr13 | |
Packing | Graphite | |
Handle | FC 250 | |
Technical Specification: | ||
Size | 2”-16” DN50-DN450mm | |
Pressure range | 5k 10k 16k | |
Design Standard | JIS B2031 | |
Face to Face | JIS B2031 | |
Flange Standard | JIS B2239 | |
Testing Standard | KS B 2304 | |
Product Description
Company Profile
Longyao Chengxin Valve Co., Ltd., located in weijiazhuang Industrial Park, Longyao County, Hebei Province, is a professional company for manufacturing and selling valves and castings. The company was founded in 1993 and established as Longyao Chengxin Valve Co., Ltd. In 2005. After its establishment, due to the accurate market positioning, excellent quality and standardized internal management, the company has become a modern enterprise with considerable scale, and has a high reputation in the valve and casting industry in China.
The company always adheres to the concept of integrity management and always adheres to the road of development strategy. Up to now, the company covers an area of more than 70000 square meters, with more than 400 employees, including more than 30 engineering and technical personnel and senior management personnel, with an annual output of nearly 11000 tons of various valves.
The company always adheres to the concept of integrity management and always adheres to the road of development strategy. Up to now, the company covers an area of more than 70000 square meters, with more than 400 employees, including more than 30 engineering and technical personnel and senior management personnel, with an annual output of nearly 11000 tons of various valves.
The company has passed the ISO 9001: 2008, 14001: 2004 quality and environmental management system certification, and obtained the special equipment manufacturing license of the people's Republic of China. It is a member of China general machinery valve Association and has the right of import and export.
Production Process
Certifications
We passed the authentication of ISO9001:2008 quality management system and ISO14001:2004 environment management system.
Offline Exhibition Display
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
Q: Are you trading company or manufacturer ?
A: We are a professional valve factory Located In Hebei, China.
Q: What's Execution Standard of products?
A: ISO,ANSI,AWWA,API,DIN,BS,JIS,EN,GOST,AS standard.
Q: How long is your delivery time?
A: Generally it is 15 days if the goods are in stock. It is 25-30 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, Welcome sample order to test and check the quality of products. The sample amount is less than $100, the product cost is free, and the customer needs to pay the express delivery fee. If the sample amount is higher than $100, and the sample cost and express delivery fee need to be negotiated by both parties.
Q: What is your terms of payment ?
A: 30% T/T in advance ,70% balance before shipment or see copy of bill of lading.
Q: Can you OEM or ODM?
A:Yes, we have a strong research & development team. The products can be made according to your request.
Q: Can you provide the relevant documentation and certificate?
A:Yes, We can provide the international certificates and relevant chemical analysis, mechanical properties, pressure test reports according to the customers need.
Q: What is your terms of delivery?
A: We accept EXW,FOB,CIF etc.
Q:How to deal with after sales ?
A: warranty time : 12 months from the shipment ; and we will be responsible for all the quality problems. We will provide process guidance services, replacement parts, on-site guidance and maintenance services. (both parties shall negotiate the relevant expenses)
Q: Why choose us?
A: 1. 20 years of manufacturing and developing experience;
2. A Strong R & D team;
3. Service experience for thousands of customers at home and abroad;
4. Export to 30 countries including Southeast Asia, East Asia, Eastern Europe and Central Asia;
5. Five casting production lines with stable casting quality, high production efficiency and fast delivery time
Q: Do you have agent or representative abroad?Can we join you?
A: Yes,We have some agents abroad. You have experience in valve and related industries. Welcome to join us. We will provide you with professional service and strong support to win more market share
