I. Product Overview:
The BOS-3051MD series online densitometers can conduct online density measurement for various liquids or liquid mixtures. They are widely used in the petrochemical industry for petroleum, oil refining, oil blending, and oil-water interface detection. In the food industry, they are applied in production sites such as grape juice, tomato juice, fruit syrup, vegetable oil, and soft drink processing. They are also used in the dairy industry, paper industry for testing black pulp, green pulp, white pulp, and alkaline solutions, as well as in industries like wine alcohol content testing and chemical urea production.
II. Technical Indicators:
4~20mA current output. Optional digital signal (HART protocol)
16~30VDC power supply. It is recommended to use 24VDC.
Density range: 0～2 g/cm³; 0~3 g/cm³
Accuracy:0.5%
Resolution: 0.001 g/cm³
Temperature range: 0～80℃
Ambient temperature: -10～60℃
-
Humidity range: 0-90%
