Linyi Power Metal Products Co., Ltd, established in 2005 as a professional manufacturer with over 15 years of expertise, proudly presents our premium Concrete Fixing Nails engineered for demanding construction applications. Operating from our 1,000-3,000 sqm facility in Shandong, China, we've supplied reliable construction solutions to South America, Southeast Asia, Africa, Mid East, and South Asia through Qingdao Port, with annual exports valued at US$1-1.5 million. Our specialized fixing nails combine robust engineering with dedicated technical support to ensure structural integrity in critical building projects.
These high-performance fasteners are designed for permanent anchoring in concrete, brick, and block substrates, providing exceptional holding power even under dynamic loads. Backed by our team of 51-100 skilled professionals, we deliver not just products but comprehensive installation guidance tailored to your project specifications.
Core Technical Advantages:
- Superior Material Engineering: Manufactured from high-carbon steel with precise heat treatment for optimal hardness (HRC 50-55) and ductility balance
- Advanced Corrosion Protection: Electro-galvanized surface treatment provides uniform zinc coating (min. 8μm) for long-term rust resistance in humid environments
- Engineered Point Design: Diamond or chisel point configurations available for rapid penetration without substrate spalling
- Vibration Resistance: Unique knurled shank design prevents loosening under continuous dynamic loads
- Load-Optimized Profiles: Multiple diameter options (2.5mm-6.0mm) with length customization (25mm-150mm) for specific load requirements
Performance Specifications:
| Parameter | Standard Range | Testing Standard |
| Tensile Strength | 1,020-1,220 MPa | ISO 6892-1 |
| Shear Load Capacity | 3.2-18.5 kN* | ASTM E488 |
| Embedment Depth | Min. 30mm in C25 concrete | ACI 318 |
| Salt Spray Resistance | 240+ hours white rust | ASTM B117 |
*Varies by diameter and embedment depth
Project-Specific Benefits:
- Reduced Installation Time: Optimized point geometry allows direct driving without pre-drilling in most concrete grades
- Structural Integrity Assurance: Controlled hardness profile prevents brittle failure in seismic zones
- Cost-Efficient Maintenance: Extended corrosion resistance minimizes replacement frequency in coastal infrastructure
- Technical Collaboration: On-call engineering support for load calculations and installation best practices
With a proven track record supplying major construction projects across five continents, our manufacturing expertise ensures consistent quality control through every production batch. The combination of our vertically integrated manufacturing (from wire drawing to final inspection) and export experience with over US$1 million annual shipments positions us as your reliable partner for critical fastening solutions. We invite contractors and distributors to leverage our technical capabilities for custom specifications including special coatings, packaging, and length-diameter combinations – all supported by responsive communication from inquiry to delivery.
Frequently Asked Questions:
Q1: What installation tools are recommended?
A: Pneumatic nail guns (0.28-0.35 cubic feet/minute capacity) with 90-100 PSI operating pressure. We provide tool compatibility charts.
Q2: Can these nails be used in pre-cast concrete?
A: Yes, but maximum edge distance should be 5x nail diameter. Consult our tech team for specific panel thickness.
Q3: What's the maximum load capacity?
A: Shear capacity ranges from 3.2kN (2.5mm) to 18.5kN (6.0mm) in C30 concrete. Download our engineering tables.
Q4: Do you provide corrosion warranties?
A: Our standard galvanized nails offer 5-year performance in moderate environments. Special coatings available for extended protection.
Q5: How do I prevent concrete cracking during installation?
A: Use our diamond-point nails and maintain minimum 6x diameter spacing between fasteners. Avoid edges under 50mm.
Q6: What's your MOQ for custom specifications?
A: Standard orders start at 1 ton. Custom diameters/lengths have 3-ton MOQ with 30-day lead time.
Q7: Can I get samples for testing?
A: Yes, we provide sample kits with 5 size variations. Shipping cost applies for express services.
Q8: Do you assist with installation training?
A: We offer video tutorials and PDF guides. On-site training available for bulk orders over 20 tons.
