PC4S4A1 Dual-Spectrum PTZ Camera
-
PC4 series is a compact solution that integrates HD visible light, infrared thermal imaging and PTZ system, with intelligent functions such as fire point detection, tripwire intrusion, and regional intrusion detection inside. It provides all-weather, 24/7 surveillance for scenarios such as perimeter surveillance, forest fire prevention and critical area protection.
Feature
12μm Uncooled Infrared Detector
Adopting the latest 12μm uncooled infrared detectors, integrated with advanced infrared imaging algorithms for better image quality.
Dual-Spectrum Imaging
All-weather, 24/7 security monitoring with dual thermal&visible light imaging.
Long-Range Detection
Supports 75mm and 100mm fixed-focus, as well as 25～75mm continuous zoom infrared lens to meet long-range detection needs.
Intelligent Fire Detection Algorithm
Features an integrated intelligent fire detection algorithm for efficient and accurate monitoring, as well as reduced false alarms.
Intelligent Video Analysis
Support tripwire/intrusion detection, as well as intelligent detection of fire point.
Platform Integration
Support ONVIF, provide SDK&demo for development; provide NVR and VMS software for application.
|
|
|
|
|
Specification
| Thermal Module | |
|---|---|
| Detector TypeVOx, uncooled FPA detectorsSpectral Range8~14μmNETD≤40mK(@25°C,F#1.0,25Hz)Resolution640×512Pixel Pitch12μmFocal Length75mm/25~75mm/100mm Motorized lens | |
| Optical Module | |
| Sensor4MP 1/1.8" Progressive Scan CMOSResolution2688×1520Focal Length6~336mm, 56x | |
| PTZ | |
| Pan360° continuous，0.1°~100°/sTilt-90°~+40°，0.1°~60°/sPreset1024Scan modePreset/Pattern Scan/Patrol Scan/ Linear Scan/Panorama ScanWiperwiper | |
| Smart Function | |
| Fire DetectionSupportVCASupport Line Crossing & Intrusion detection2-Way AudioSupportLinkage ActionVideo/ Snapshot/Email/Alarm output | |
| System Interface | |
| PowerDC 24V±15%Network1 RJ45 10M / 100M self-adaptive Ethernet portAudio1 in/1 outAlarm7 in/2 outStorageMicro SD memory（maximum 256G）Serial Port1 channel RS485, can support Pelco protocol | |
| General | |
| Work Environment-40℃~+70℃； | |
Application Scenarios
|
Perimeter Surveillance |
Forest Fire Prevention |
Important Area Perimeter |
River Monitoring |
