Home > Electrical & Electronics > Electric Motor > DC Motor > Hot Selling 5225 Brushless Motor for Lawn Mowers - Perfect for Electrician Tools!
Hot Selling 5225 Brushless Motor for Lawn Mowers - Perfect for Electrician Tools!
US$ 19
40 - 399 Units
US$ 18
400 - 3999 Units
US$ 17
≥4000 Units
Key Specifications
Get Latest Price
Type:
Other
Certification:
Other
Function:
Driving
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
30 days
Related Products
-
DCA2 Built-in Angle Grinder Brushless Motor - 52×38mm Steel Core, High Torque & Long Life!US$ 22 - 25MOQ: 10 Units -
DCR6 Inner-Rotor Brushless Motor - Ø48mm Steel Core + Cooling Fan & Controller, Power Up Your Tools!US$ 10 - 12MOQ: 10 Units
-
DCW8 16.8v Inner-Rotor Brushless Motor - Ø48mm Steel Core + Cooling Fan & Controller, Power Up Your Tools!US$ 10 - 14MOQ: 100 Units
-
20V DCE6 Lithium-Ion Impact Wrench With Brushless Motor, Driver, and DC Motor for Application in the Electric Tool Industry.NegotiableMOQ: 20 Units
-
20V DCW9 Lithium-Ion Impact Wrench With Brushless Motor, Driver, and BLDC Motor for Application in the Electric Tool IndustryNegotiableMOQ: 20 Units
Type
Other
Certification
Other
Function
Driving
Application
Industrial, Household Appliances, Power Tools, Other
Brand
Other
Excitation Mode
Other
Number of Poles
2
Casing Protection
Closed Type
Structure and Working Principle
Brushless
Operating Speed
Low Speed
Origin
China
Technical Requirements
Motor Rotation Direction: CCT – Rotates counterclockwise when viewed from the output shaft end.
Rated Voltage: DC18V
No-load Speed: 3500±5% rpm at DC18V
No-load Current: 0.7A MAX
Withstand Voltage Test: AC500V / 1S / 5mA MAX
Motor Backlash: 0.2mm MAX
Unmarked Tolerances for Dimensions and Angles: Comply with GB/T 1804.
Unmarked Geometric Tolerances: Comply with GB/T 1804-k.
Motor Operation: Run smoothly without obvious defects such as vibration and noise.
Component Compliance: All motor components must meet RoHS requirements.
