As a specialized manufacturer based in Xuzhou, Jiangsu, Xuzhou Guozi Intelligent Technology Co., Ltd. delivers cutting-edge Electrically Conductive Carbon Fiber Yarn engineered for next-generation applications. Our innovative yarn combines the strength of carbon fiber with advanced conductive properties, creating essential components for EMI shielding solutions and smart textile development. With over a decade of materials expertise, we provide reliable conductive yarns that meet rigorous industrial demands while enabling breakthrough innovations in wearable technology.
Core Technical Advantages:
- Precision-engineered conductivity ranging from 10-2 to 102 Ω/cm
- Maintains flexibility with breaking strength exceeding 200 cN/tex
- Exceptional EMI shielding effectiveness (tested up to 70 dB at 1 GHz)
- Thermal stability across -40°C to 150°C operating range
Performance Specifications:
| Parameter | Standard Value | Customization Range |
|---|---|---|
| Yarn Diameter | 0.5 mm | 0.2-1.5 mm |
| Linear Resistance | 100 Ω/cm | 10-2-103 Ω/cm |
| Tensile Strength | 250 MPa | 150-400 MPa |
| Temperature Resistance | -40°C to 120°C | Extended ranges available |
This conductive yarn enables seamless integration into textile structures through standard weaving and knitting processes. The material's corrosion resistance ensures long-term performance in medical textiles, military apparel, and industrial shielding applications. Our proprietary coating technology prevents conductivity degradation after 50+ industrial wash cycles, significantly extending product lifespan compared to conventional solutions.
Application-Specific Benefits:
- EMI Shielding: Creates Faraday cages in composite materials for sensitive electronics protection
- Wearable Tech: Enables embedded sensors and connectivity in smart garments without compromising comfort
- Industrial Textiles: Provides static dissipation in hazardous environments and cleanrooms
- Research & Development: Accelerates prototyping of functional textiles with reliable conductivity
Backed by Xuzhou Guozi's advanced manufacturing facilities in Jiangsu, we maintain strict quality control throughout production. Our technical team provides application support from material selection through integration testing. With flexible minimum order quantities and rapid prototyping services, we empower both startups and established manufacturers to innovate confidently.
Frequently Asked Questions:
Q1: How does this compare to metal-based conductive threads?
A: Our carbon fiber yarn offers superior flexibility, lighter weight (approx. 30% reduction), and better corrosion resistance while maintaining comparable conductivity.
Q2: Can this yarn be integrated with automated textile machinery?
A: Yes, it's compatible with standard industrial looms and knitting machines at speeds up to 500 rpm without special modifications.
Q3: What's the minimum conductivity achievable?
A: We can achieve surface resistivity down to 0.1 Ω/sq through specialized coating processes for critical applications.
Q4: Do you provide custom spooling configurations?
A: Custom spool sizes from 500m to 10,000m are available, with specialized winding tension control upon request.
Q5: How does washing affect performance?
A: The conductive coating maintains >95% effectiveness after 50 wash cycles at 40°C using industrial detergent.
Q6: Can different colors be provided?
A: Standard black is available, with custom coloration options for specific aesthetic requirements.
Contact our Jiangsu-based engineering team today to discuss how our conductive yarn solutions can enhance your EMI shielding or smart textile project. With dedicated R&D facilities and flexible manufacturing capabilities, Xuzhou Guozi delivers technically advanced materials that meet your precise performance requirements and production timelines.
