The Gantry Shears use upper compression and compression on both sides of the scrap shaping and segmented feeding way, coupled with the design of a large material box, so good adaptability to scrap raw materials, and high density after shear.
The box opening area is large, suitable for mechanical feeding, suitable for loose light and thin scrap steel and steel structure, especially suitable for steel pipe, steel plate, and channel profile shearing.
Adopt the screen display control panel, automatic integrated control, stable and reliable operation. Optional wireless remote control device, single control production line equipment
The use of reliable large flow logic valve control, independent filtration, and cooling can ensure the system's efficient and reliable operation. The comprehensive application of constant power variable and differential fast technology can save about 25%energy while ensuring output, and the energy consumption of steel processing per ton is lower than the requirements of industry standards.
| GANTRY SHEARS | ||||||
| Model | Max Shear Force(Ton) | Press Box Size(mm) | Blade Length (mm) | Prodution Rate(Tons/hr) | Cutting Frequency (Times/min) | Main Motor Power (kw) |
| Q91Y-315 | 315 | 6000*1200*550 | 1200 | 3-5T | 3 | 2*30 |
| Q91Y-400 | 400 | 6000*1400*650 | 1400 | 5-7T | 3 | 2*45 |
| Q91Y-500 | 500 | 6000*1600*650 | 1600 | 7-9T | 3 | 3*45 |
| Q91Y-630 | 630 | 7000*1600*700 | 1600 | 9-12T | 3 | 3*45 |
| Q91Y-630 | 630 | 7000*1800*700 | 1800 | 12-16T | 3 | 4*45 |
| Q91Y-800 | 800 | 8000*2000*800 | 2000 | 16-20T | 3 | 2*90 |
| Q91Y-1000A | 1000 | 8000*2000*900 | 2000 | 20-25T | 3 | 4*90 |
| Q91Y-1000B | 1000 | 8000*2500*1000 | 2500 | 20-28T | 3 | 4*90 |
| Q91Y-1600 | 1600 | 8000*2000*1200 | 2500 | 25-30T | 3 | 5*90 |
FAQ
Q: What types of metal materials can your Longmen shears process?
A: Our Longmen shears are designed to handle a wide variety of metal materials. They can process thin-walled pipes, thick-plate metals, and various shapes of metal scraps. Whether it's ferrous metals like steel and iron, or non-ferrous metals such as aluminum and copper, our Longmen shears can efficiently shear them according to the required specifications.
Q: Can your metal balers be customized for specific bale sizes and shapes?
A: Absolutely. We understand that different customers have different requirements for bale sizes and shapes in the metal recycling and processing industry. Our metal balers can be customized to produce bales in square, rectangular, or other special-shaped configurations. You just need to provide us with your specific size and shape requirements, and we will design and manufacture the equipment accordingly.
Q: How does your company ensure the quality of Longmen shears and metal balers?
A: We have a rigorous quality control system. Firstly, all raw materials are strictly inspected before entering the factory to ensure they meet high-quality standards. During the production process, there are multiple quality-control checkpoints. Workers conduct self-inspections at each operation step, and our quality control personnel perform regular and random sampling inspections. Finally, before the products leave the factory, a comprehensive final inspection is carried out, covering all aspects of product performance, appearance, and safety. Only products that meet all quality requirements can be delivered to customers.
Q: What after-sales services do you offer for the products?
A: We provide a comprehensive after-sales service. Once you encounter problems during the use of our Longmen shears or metal balers, our professional after-sales service team will respond promptly. We can offer remote technical support through telephone, video, or online platforms. If necessary, we will dispatch technicians to your site to solve the problems on-site. In addition, we also offer regular product maintenance and inspection services to ensure the long-term stable operation of the products. We provide a one-year warranty for all products, and during the warranty period, if there are any quality problems caused by the manufacturer, we will be responsible for free repair or replacement.
Q: Do you provide installation and training services for the newly purchased equipment?
A: Yes, we do. When you purchase our Longmen shears or metal balers, we will arrange professional technicians to provide on-site installation services to ensure that the equipment is installed correctly and can operate normally. After the installation is completed, our technicians will also provide training for your operators. The training content includes equipment operation, daily maintenance, and simple troubleshooting, so that your operators can quickly master the operation skills of the equipment and ensure the efficient operation of the equipment.
