1. Product Overview
The marine valve flange F7320 JIS 10K cast steel angle valve combines the flange connection mode and the pressure rating of the JIS 10K standard. It is made of high-quality cast steel. This valve is designed for use in ship pipeline systems. It has a right-angle flow channel structure and can control the pressure, flow rate, and flow direction of fluids. Its excellent sealing performance and corrosion resistance make it suitable for various media and high-temperature and high-pressure environments, ensuring the safe and stable operation of the ship system.
2. Product Features
Excellent Material: Made of high-quality cast steel, it has good mechanical properties and corrosion resistance, and can withstand the high temperature and high pressure in the ship pipeline system and the erosion of various media.
Excellent Sealing Performance: The sealing surfaces between the valve disc and the valve seat are precisely machined and matched to ensure excellent sealing performance in the closed state and effectively prevent medium leakage.
Compact Structure: The product is designed to be compact, occupying a small space, which is convenient for installation and use in the limited space of the ship. At the same time, its right-angle flow channel structure also reduces the flow resistance of the fluid in the valve.
Wide Range of Applicable Media: Suitable for various media on ships, such as fresh water, seawater, fuel oil, lubricating oil, steam (temperature less than or equal to 300°C), air, gas, etc.
Easy to Operate: The valve opens and closes flexibly and is easy to operate. It can quickly respond to various operation instructions to ensure the normal operation of the ship system.
3. Technical Specifications
Model: F7320
Standard: JIS 10K
Material: Cast steel
Connection Method: Flange connection
Pressure Rating: 10K (equivalent to a certain pressure range)
Nominal Diameter: Multiple caliber options are available, such as 50mm, 65mm, 80mm, 100mm, 125mm, 150mm, 200mm, 250mm, 300mm, etc., to meet the needs of different pipeline systems.
Working Temperature: Suitable for various temperature environments. The specific working temperature range depends on the selection of the medium and the sealing material.
Flow Direction: Unidirectional flow
Driving Method: Manual or other optional driving methods
4. Application Scope
This valve is widely used in various liquid and gas pipeline systems in the shipbuilding industry, such as fuel systems, cooling systems, fire protection systems, steam systems, etc., to cut off or regulate the flow of the medium. Its excellent sealing performance and wide applicability to various media make it an indispensable valve product in the shipbuilding industry.
V. Installation and Maintenance
Installation: Before installation, check whether the model and specifications of the valve meet the design requirements, and inspect all components of the valve to ensure they are in good condition. During installation, follow the standards for flange connections to ensure tight and reliable connections. Meanwhile, pay attention to the flow direction and installation position of the valve to ensure it can open and close normally.
Maintenance: Regularly maintain the valve, such as cleaning and lubricating, to ensure its normal operation and extend its service life. At the same time, regularly check the sealing performance and usage of the valve, detect problems in time and handle them. During the maintenance process, be careful not to damage the valve or affect its performance.
