Automatic BOD Measuring Instrument, WTW Germany
I. Detailed Introduction
(1) Features
1. No need to dilute samples;
2. Automatic temperature compensation function;
3. Measured values can be automatically stored.
(2) Mercury-free BOD Test
BOD is one of the important indicators for evaluating the quality of water resources and reflects the amount of biodegradable substances in water and wastewater. The OxiTop® system provided by WTW Company is a brand-new mercury-free measurement system, which can not only be used for BOD detection but also measure biodegradation and consumption capacity. The advantages of OxiTop and OxiTop Control are simple operation, easy control, non-toxicity, and a high measurement range up to 400,000 mg/l BOD (using OxiTop® Control OC 110). Due to the automatic conversion of the measured pressure, the reading is directly in mg/l BOD.
Model |
OxiTop |
OxiTop Control OC 100 |
OxiTop Control OC 110 |
Application |
Regular BOD |
Regular BOD, Standard BOD |
Regular BOD, Standard BOD and Special BOD, Respiration Rate/Dilution, Soil Respiration Rate, Biodegradation, Biogas Detection |
BOD Measurement Range |
0–4000mg/l |
0–4000 mg/l |
0–400000mg/l |
Measurement Value Storage |
5 days |
0.5 hours – 99 days |
0.5 hours – 99 days |
Pressure Mode |
— |
— |
Pressure p 500 – 1.350 hPa |
Sample volume |
Fixed |
Fixed |
Configurable |
II. Application scope
Model |
OxiTop |
OxiTop Control OC 100 |
OxiTop Control OC 110 |
Application |
BOD routine |
BOD routine, BOD standard |
BOD routine, BOD standard and BOD special, Respiration rate/dilution, Soil respiration rate, Biodegradation, Biogas detection |
BOD measurement range |
0–4000mg/l |
0–4000 mg/l |
0–400000mg/l |
Measurement value storage |
5 days |
0.5 hours – 99 days |
0.5 hours – 99 days |
Pressure mode |
— |
— |
Pressure p 500 – 1.350 hPa |
Sample volume |
Fixed |
Fixed |
Configurable |
3. OxiTop is supplied as a complete set for 6 or 12 measuring bottles
Model |
OxiTop® |
OxiTop® Control |
|||||||||||
IS 6/ IS 12 |
6 / 12 |
B6 / B6M / B6M2.5 |
A6 /A12 |
S6 / S12 |
AN6 / AN12 | ||||||||
Measuring bottle |
510 ml |
510 ml |
500 ml / 1.0 l / 2.5 l |
1.0 l/250 ml |
510 ml |
1.0 l/250 ml |
|||||||
Quantity |
6 / 12 |
6 / 12 |
6 / 6 / 6 |
6 / 12 |
6 / 12 |
6 / 12 |
Measuring head |
OxiTop® |
OxiTop®-C |
OxiTop®-C |
OxiTop®-C |
OxiTop®-C |
OxiTop®-C |
Stirrer |
IS 6/IS 12 |
IS 6/IS 12 |
— |
IS 6-Var/IS 12 |
IS 6/IS 12 |
IS 6-Var/IS 12 |
|||||||
Controller |
— |
OC 100 |
OC 110 |
OC 110 |
OC 110 |
OC 110 |
|||||||
Software and cable |
— |
— |
● |
● |
● |
● |
|||||||
CO2 absorbent |
● |
● |
● |
● |
● |
● |
|||||||
Nitrification inhibitor |
● |
● |
— |
● |
● |
● |
|||||||
Overflow measuring flask |
164/432 ml |
164/432 ml |
— |
— |
— |
— |
|||||||
Stir bar |
6/12 |
6/12 |
— |
6/12 |
6/12 |
6/12 |
|||||||
Stir bar retriever |
● |
● |
— |
● |
● |
● |
|||||||
Drawing paper |
● |
● |
— |
— |
— |
— |
|||||||
Application |
BOD |
BOD |
Soil respiration rate |
Aerobic/anaerobic application |
Aerobic application |
Anaerobic application |
|||||||
3. OxiTop is supplied as a complete set for 6 or 12 measuring bottles
