Help CenterIndustrial Self-Regulating Heat Trace Cable With Automatic Temperature Control, UL Listed
Related Products
-
Self-Regulating Heating Cable for Metal and Plastic Pipes, -40°F to 150°F, 10W/ft at 50°FNegotiableMOQ: 100 Meters -
Self-Regulating Heating Cable for Pipe Freeze Protection, 10W/ft, 120V, 3/8" to 2" Pipe DiameterNegotiableMOQ: 100 Meters
-
Commercial Self-Regulating Heating Cable for Pipes and Tanks, 12W/ft, 208-277V, Hazardous Area RatedNegotiableMOQ: 100 Meters
-
Self-Regulating Heating Cable for Long Distance Pipe Freeze Protection - Energy Efficient SolutionNegotiableMOQ: 100 Meters
-
Polymer PTC Heat Tracing Belt for Long Distance Pipe Networks - Automatic Temperature ControlNegotiableMOQ: 100 Meters
As a leading manufacturer based in Jinan, Shandong, Shandong Huaning Electric Heating Technology Co.,Ltd specializes in advanced thermal solutions for industrial applications. Our Industrial Self-Regulating Heat Trace Cable with Automatic Temperature Control delivers precision freeze protection while significantly reducing energy consumption. Designed for harsh environments, this UL-certified solution ensures operational continuity and minimizes maintenance costs.
Core Advantages:
- Energy-Efficient Operation: Automatically adjusts heat output based on pipe temperature changes
- Fail-Safe Design: Eliminates burnout risks even when overlapped during installation
- Low Maintenance: Durable fluoropolymer construction withstands chemicals and UV exposure
Technical Specifications:
| Power Rating (per meter) | 10W to 30W at 10°C |
| Maximum Exposure Temperature | 65°C continuous |
| Minimum Bending Radius | 25mm at -20°C |
| Jacket Material | Flame-retardant fluoropolymer |
Installation Benefits:
- Cut-to-length flexibility allows customization on-site
- Compatible with standard thermal insulation materials
- Suitable for metal/plastic pipes up to 4" diameter
For over a decade, our Jinan-based facility has supplied thermal management systems to oil refineries, chemical plants, and water treatment facilities across China. This cable's UL certification validates its compliance with rigorous electrical safety standards. We recommend pairing it with our HNC-TR thermostat (sold separately) for critical temperature monitoring.
FAQ Section
Q1: Can this cable be used on plastic pipes?
A: Yes, its self-regulating feature prevents overheating on plastic surfaces.
Q2: Is an external controller required?
A: While functional without controllers, we recommend thermostats for energy optimization.
Q3: What's the maximum circuit length?
A: Up to 150 meters for 120V systems; consult our engineering guide for specifics.
Q4: Does it require special termination kits?
A: Standard heat trace end seals and power connection kits are compatible.
Q5: How does it perform in wet locations?
A: The fluoropolymer jacket provides IP67 protection against moisture ingress.
Q6: Can it be repaired if damaged?
A: Minor jacket damage can be sealed with epoxy; core damage requires replacement.
Q7: What maintenance is needed?
A: Annual inspection of power connections and insulation integrity is recommended.
Q8: Is cold-weather installation possible?
A: Yes, it remains flexible down to -40°C for winter installations.
