Chemical reactor (Mechanical Seal)
【 summary 】
Mechanical seal reactor is a container for physical or chemical reaction. It is widely used in petroleum, chemical, rubber, pesticide, dye, medicine, food and other industries. Through the structural design and parameter configuration of mechanical seal reactor, the heating, evaporation, cooling and mixing functions of low and high speed are realized.
【 apply 】
Mechanical seal reactor is used to complete the process of hydrolysis, neutralization, crystallization, distillation, evaporation, storage, hydrogenation, hydrocarbonation, polymerization, condensation, heating mixing, constant temperature reaction, etc.
【 structural composition 】
The mechanical seal reactor consists of the reactor body (cylinder), reactor cover (head), jacket or coil (heating and cooling circulation), agitator (anchor, paddle, turbine, etc.), drive device (motor-reducer), shaft seal device (mechanical seal), support (platform, legs), and heat preservation medium.
【 fittings of a machine 】
The accessories of mechanical seal reactor can be installed CIP cleaning device, liquid level gauge (level gauge), manhole (hand hole), breather (fireproof explosion-proof), sight glass spotlight, temperature sensor, pressure gauge, vacuum gauge, lower extension discharge valve, etc.
【 technical parameter 】
nominal capacity |
100L |
300L |
500L |
1000L |
2000L |
3000L |
5000L |
10000L |
Inner diameter (mm) |
500 |
800 |
900 |
1100 |
1400 |
1500 |
1800 |
2100 |
Heat transfer area (m²) |
0.9 |
2 |
2.7 |
4.5 |
7.5 |
10 |
13.5 |
22 |
power of agitator （KW） |
0.55 |
0.75 |
1.5 |
3 |
4 |
5.5 |
7.5 |
11 |
speed （r/m） |
Constant speed or variable frequency speed control |
|||||||
mixing form |
design and manufacture according to material properties |
|||||||
Work pressure (Mpa) |
Design and manufacture according to process conditions |
|||||||
working temperature ℃ |
-20°-300° |
|||||||
jacket heating/cooling medium |
Steam, heat transfer oil/cooling water, and refrigerant oil |
|||||||
heat insulating material |
Polyurethane/rock wool |
|||||||
Orifice configuration |
Design can be performed as needed under specified conditions |
|||||||
Tank material |
SUS304/316L or other corrosion-resistant stainless steel lining materials |
|||||||
class |
Atmospheric Pressure/Category 1 |
|||||||
remarks |
The above information is for reference only. For details, please contact our company design and production. |
|||||||
