As a leading manufacturer in recycling machinery since 2022, Henan Riku Machinery Equipment brings you this heavy-duty hydraulic scrap iron baling machine designed specifically for industrial recycling operations. Our ISO9001-certified facility in Zhengzhou combines engineering expertise with rigorous quality control to deliver compactors that maximize material density and operational efficiency.
Core Product Advantages:
High-pressure hydraulic system delivers up to 150 tons compression force
Customizable bale sizes from 600x400mm to 1200x800mm
Automatic wire tying system reduces labor requirements
Wear-resistant manganese steel blades extend service life
PLC-controlled operation with touchscreen interface
Technical Specifications:
Main Applications
Ideal for metal recycling plants, scrapyards, foundries, manufacturing facilities, and automotive dismantling operations
Functional
To efficiently compress loose and scattered metal scrap (such as steel, aluminum, copper, stainless steel, and car shells) into high-density, regularly shaped bales for easy transportation, storage, and recycling
Working principle
Operates on a hydraulic system. A motor drives a hydraulic pump to create high pressure, which extends hydraulic cylinders to push a ram (platen) that horizontally compacts the metal inside a strong chamber
Characters
Ejection Methods :Offers various ejection styles to suit different layout and workflow needs, including side-push, side-flip, and front-push mechanisms.
Control System:Features Programmable Logic Controller (PLC) for automated operation, allowing for simple button-controlled cycles, consistent performance, and reduced manual labor. Manual control options are also available for specific needs.
Safety Features:Equipped with essential safety devices such as emergency stop buttons, safety door switches, and overload protection systems to ensure operator safety.
Key Advantages and Value Proposition
High Efficiency & Cost Reduction: This machine significantly increases the density of metal scrap (by 3-10 times), drastically reducing its volume. This leads to substantial savings in storage space and transportation costs .
Automation & Labor Saving: The PLC-controlled automatic operation minimizes the need for manual labor, improving overall workflow efficiency and consistency while reducing operational costs .
Durability & Reliability: Built with high-strength steel plates and wear-resistant components, these balers are designed for heavy-duty use and have a long service life, ensuring a stable and reliable performance .
Environmental Benefits: By promoting metal recycling and optimizing logistics, the baler helps reduce the carbon footprint associated with waste transportation and primary metal production, supporting sustainability goals.
Technical parameters
type |
working chamber mm |
bale size |
capacity |
Main power kw |
Y125 |
1200*700*600 |
300*300 |
1.5T/H |
18.5 |
Y160 |
1600*1000*700 |
400*400 |
2-3t/h |
22 |
Y200 |
1800*1200*750 |
450*450 |
3-4t/h |
30 |
Y250 |
2000*1750*800 |
500*500 |
5-6t/h |
2*22kw |
Y315 |
2500*2000*900 |
600*600 |
6-8t/h |
2*37kw |
Y400 |
3000*2000*950 |
600*600 |
10-12t/h |
2*45kw |
Y600 |
3500*2500*1000 |
600*600 |
15-20t/h |
2*45kw |
Operational benefits include reduced transportation costs through increased material density and minimized manual handling risks. The modular design allows for quick component replacement, while the centralized lubrication system ensures minimal maintenance downtime. Our machines feature overload protection and hydraulic oil cooling systems to prevent overheating during continuous operation.
Backed by our annual export volume of US$1.5-2.5 million to 14 global markets including North America and Southeast Asia, this compactor represents proven industrial technology. With over 50% of our 11-50 workforce dedicated to R&D in our 3,000-5,000㎡ facility, we continuously refine performance and safety features based on international client feedback.
Frequently Asked Questions:
Q: What scrap materials can this machine process?
A: Designed primarily for ferrous metals including iron, steel, and automotive scrap, with optional configurations for non-ferrous materials.Q: How often does the hydraulic system require maintenance?
A: Standard maintenance intervals are every 500 operating hours with oil changes recommended every 2,000 hours.Q: Can the machine be customized for specific facility layouts?
A: Yes, we offer left/right-hand feeding configurations and conveyor integration options.Q: What safety certifications does the equipment have?
A: Manufactured under ISO9001 standards with CE certification available upon request.Q: What is the expected service life?
A: Structural components feature a 10-year design life with proper maintenance.Q: Do you provide installation support?
A: Comprehensive technical documentation and video guidance are included, with optional on-site commissioning services.
This industrial-grade compactor delivers measurable ROI through reduced scrap volume and handling costs. Contact our engineering team to discuss specific capacity requirements and receive a customized solution proposal within 24 hours.
