CW6163 Series Horizontal Lathe
The CW6163 Series Horizontal Lathe is suitable for machining small and medium-sized parts of various steels. It can turn the inner hole, outer circle, end face, cone of various workpieces, as well as various threads (metric, imperial, module, and diametral pitch threads), and can also perform functions such as drilling and boring. Main features: 1. The spindle has four gears + variable frequency stepless speed regulation, which can achieve gear shifting without stopping the machine. The speed regulation range is wide, which can meet the needs of rough and finishing processes. 2. The spindle speed range is 17 - 1000r/Min, and the through-hole diameter is Φ100mm. 3. The bed is made of high-strength castings using resin sand molding. The bed guide rails are treated with super-audio frequency quenching and precision grinding, with good wear resistance and precision retention, and strong bearing capacity. 4. The apron is equipped with a safety mechanism to prevent damage to the machine tool due to overload. 5. There are longitudinal and transverse power and rapid movement handles for the tool post, which are flexible to operate and user-friendly. 6. It has two feed systems: metric and imperial. 7. Electrical systems with different voltages and frequencies can be provided for different countries and regions.
Main technical parameters
Technical specifications Model CW6180 CW6280 CW6163 CW6263 CQW61100 Working range Swing diameter over the bed 800mm 630mm 1000mm Workpiece length 1-10 M Swing diameter on the cross slide (automatic feed) 510（490）Mm 350mm 710（690）Mm Swing diameter over the gap × effective width 1000×350mm 800×350mm 1200×350mm Width of the bed guide rail 600mm Load capacity between chucks 3T Spindle Spindle bore diameter Φ100mm Taper of the spindle taper hole Metric 120# Spindle speed range 17-1000r/Min (four - speed, stepless) Spindle head model Type C 11 Feed Longitudinal feed range 0.1-12.2mm/R Transverse feed range 0.05-6.6mm/R Rapid traverse speed of the slide 3.8m/Min Metric thread range 1-120mm, 47 types Imperial thread range 28-1/2t/Inch, 25 types Module thread range 0.5-60mm, 45 types Diametral pitch thread range 28-1t/Inch, 29 types Cross slide travel 449mm Compound rest travel 200mm Tailstock Tailstock spindle diameter Φ120mm Tailstock spindle travel 200mm Tailstock spindle hole taper Morse taper No. 6 Power parameters Main motor power 15kW Rapid motor power 1.1kW Cooling motor power 0.15kW Total power 22kW Overall dimensions and weight
Length CW6180 CW6163 CQW61100 Overall Dimensions (Length × Width × Height) Net Weight Overall Dimensions (Length × Width × Height) Overall Dimensions (Length × Width × Height) 1000 3000×1400×1370 5.8 3000×1400×1290 3000×1400×1470 2000 4000×1400×1370 6.6 4000×1400×1290 4000×1400×1470 3000 5000×1400×1370 7.4 5000×1400×1290 5000×1400×1470 4000 6000×1400×1370 8.2 6000×1400×1290 6000×1400×1470 5000 7000×1400×1370 9.0 7000×1400×1290 7000×1400×1470 6000 8000×1400×1370 10.2 8000×1400×1290 8000×1400×1470 7000 9000×1400×1370 11 9000×1400×1290 9000×1400×1470 8000 10000×1400×1370 11.8 10000×1400×1290 10000×1400×1470 9000 11000×1400×1370 12.6 11000×1400×1290 11000×1400×1470 10000 12000×1400×1370 13.4 12000×1400×1290 12000×1400×1470 Random accessories
1. Φ380 three-jaw chuck/1 piece 2. Morse No. 6/1 piece 3. Heavy-duty precision slewing/1 piece 4. Set/1 piece 5. Lighting device/1 set 6. Cooling device/1 set 7. Common tools/1 set
Optional accessories
1. Φ500 four-jaw chuck 2. Φ50 - Φ300 center rest 3. Φ50 - Φ150 follower rest, Φ150 - Φ300 follower rest 4. Taper turning device 5. Automatic feed for small tool post (Optional for specifications above CW6180), Swing diameter over cross slide Φ490 6. Φ260 - Φ450 center rest (Optional for specifications above CW6180) 7. Φ300 - Φ630 center rest (For CQW61100)
