The fast anti-harmonic intelligent power capacitor is designed for the situation where the harmonic content of the power network is large, the reactive power changes rapidly, and ordinary power capacitors cannot operate normally. It uses special technologies and processes and is composed of a circuit breaker, thyristor, reactor, and aluminum-shell low-voltage power capacitor. It has the characteristics of fast response speed, zero-crossing switching of the capacitor, no inrush current impact, effectively extending the service life of the capacitor, no amplification effect on harmonics, and the ability to absorb some harmonics.
The busbar (hereinafter referred to as the busbar) is suitable for circuits with a rated heating current up to 100A, AC 50/60Hz, and a rated voltage up to 415V. It is mainly used for the connection between the same phases at the incoming line ends of multiple circuit breakers, so that the electrical equipment of the same phase is at the same potential. The busbar can be used in combination with small circuit breakers such as CB-60.
Using this product can replace 3 voltmeters, 3 power factor meters, 1 low-voltage reactive power compensation controller, and all capacitor status indicator lights on the current low-voltage reactive power compensation cabinet, making it extremely simple and saving a large amount of wiring at the same time. The intelligent molded case circuit breaker is used for AC 50Hz, rated operating voltages of 400V and 690V, and rated currentIntelligent Reactive Power CompensationCapacitoris an intelligent reactive power compensation device for 0.4kV low-voltage distribution networks to reduce line losses, improve power factor, improve power quality, and save energy and reduce consumption. Based on the intelligentReactive Power CompensationControllerThe designed reactive power compensation scheme can refer to the following principles
| Non-linear Load Ratio | Reactive Power Compensation Design Scheme | | | |
| Three-phase Balanced Static Load | Three-phase unbalanced static load | Three-phase balanced and frequently changing load | Three-phase unbalanced and frequently changing load | |
| Non-linear equipment in the load ≤ 15% of transformer capacity (mainly linear load) | Three-phase common compensation, composite switch zero-crossing switching, | Phase-separated compensation or mixed compensation, Composite switch zero-crossing switching; | Three-phase common compensation, thyristor switch dynamic switching | Phase-separated compensation or mixed compensation, Thyristor switch dynamic switching; |
| 15% | Three-phase common compensation Composite switch zero-crossing switching Connect 6% or 12% filtering reactance in series in the capacitor circuit | Phase-separated compensation or mixed compensation Composite switch zero-crossing switching Connect 6% or 12% non-tuned filtering reactance in series in the capacitor circuit | Three-phase common compensation Thyristor switch dynamic switching Connect 6% or 12% non-tuned filtering reactance in series in the capacitor circuit | Phase-separated compensation or mixed compensation Thyristor switch dynamic switching Connect 6% or 12% non-tuned filtering reactance in series in the capacitor circuit |
| Harmonic governance target | Destroy the parallel resonance between the capacitor and the system, and partially absorb the 3rd, 5th, 7th and above harmonics in the system | Destroy the parallel resonance between the capacitor and the system, and partially absorb the 3rd, 5th, 7th and above harmonics in the system | Destroy the parallel resonance between the capacitor and the system, and partially absorb the 3rd, 5th, 7th and above harmonics in the system | Destroy the parallel resonance between the capacitor and the system, and partially absorb the 3rd, 5th, 7th and above harmonics in the system |
| The ratio of non-linear equipment in the load > 50% of the transformer capacity (there are a large number of harmonics) | Three-phase common compensation Zero-crossing switching of composite switch Tuned filter circuit composed of capacitor or reactor | Phase-separated compensation or mixed compensation Zero-crossing switching of composite switch Tuned filter circuit composed of capacitor or reactor | Three-phase common compensation Dynamic switching of thyristor switch Tuned filter circuit composed of capacitor or reactor | Phase-separated compensation or mixed compensation Dynamic switching of thyristor switch Tuned filter circuit composed of capacitor or reactor |
