metal scrap crusher is for the light material. bulky material or the steel wire scrap to process them into smaller density material through the hammer squeezing, rubbing,crashing of hammer and the material, to down size of material, meanwhile to get out the impurities .cut off the cost of transportation, increase the melting ratio. there is fit with jet pulse filter to project environment.
1 the force feeding device, two stage pressing the bulky material to the crushing chamber . improve the processing efficiency. 2.Robust frame and liar to keep continue uptime.
3. Eject design to avoid heavy material damage the core part.
4. Hydraulic cylinder to open caps , which is convenient to speed up offtime.
5. The New hammer design with the cover to expand working hours.
6. The crushing chamber takes the thickness and durable material to reliable and keep Operation hours. 7. expedition of sorting device, Zig zag separator , and drum magnetic separator equipped.
Core Engineering Advantages:
Unmatched Torque Delivery: Patented drive system generates 30% higher crushing force than conventional models
Hardened Component Construction: Critical wear parts forged from 65Mn alloy steel (HRC 58-62)
Intelligent Overload Protection: Auto-reverse function prevents jamming during oversized material processing
Adaptive Feeding System: Adjustable hydraulic pusher accommodates irregular scrap shapes
Technical Specifications:
Parameter
S.N | TYPE | Voltage | power（KW) | RMP | FEEDER mm | Capacity t/h |
1 | RK-100 | 380V | 55 | 960 | 1000 | 500-600 |
2 | RK-120 | 380V | 90 | 990 | 1200 | 700-900 |
3 | RK-140 | 380V | 132 | 990 | 1400 | 1000-1500 |
4 | RK-200 | 380V | 200 | 750 | 1600 | 2000-3000 |
6 | RK-315 | 380V | 315 | 600 | 1800 | 5000-6000 |
7 | RK-450 | 380V/10KV | 450 | 600 | 2000 | 8000-10000 |
8 | RK-630 | 10KV | 630 | 600 | 1900 | 12000-15000 |
9 | RK-750 | 10KV | 750 | 600 | / | 15000-20000 |
11 | RK-900 | 10KV | 900 | 600 | 2200 | 20000-25000 |
Operational Benefits for Industrial Users:
Reduced Downstream Costs: Pre-shredded output decreases melting energy consumption by up to 40%
Minimal Maintenance: Centralized lubrication system extends service intervals to 300+ operating hours
Safety Compliance: Emergency stop circuits and mechanical locking guards meet international standards
Space Optimization: Compact footprint (approx. 6.5m x 3.2m) fits existing production layouts
Backed by our 3,000-5,000 sqm manufacturing facility and US$1.5-2.5 million annual export experience, we guarantee precise engineering for North American, European and global markets. Our 50+ technical team provides lifetime support with wear part replacements and application optimization. Request your material testing session today to experience 20% higher metal recovery rates.
Frequently Asked Questions:
Q: What scrap types can this shredder process?
A: Optimized for steel plates, automotive shells, and structural beams. Non-ferrous metals require optional blade configurations.Q: Is dust control available?
A: Integrated air filtration systems can be supplied upon request.Q: What's the lead time for production?
A: Standard units ship in 45 days; custom configurations require 60-75 days.Q: How are knives replaced?
A: Modular cartridge design enables knife changes in under 2 hours without disassembly.Q: Do you provide installation supervision?
A: Global commissioning services available through our 11-country support network.Q: Can it handle painted or coated metals?
A: Yes, special wear-resistant coatings protect against abrasive surface treatments.
