Help CenterQuick-Inflation Pneumatic Shield Dam (10m×3m) - Eco-Friendly Water Retaining Structure for Urban River
Related Products
-
Anti-Abrasion Stainless Steel PSG (12m×2m) - Heavy-Duty Barrier for River Diversion ProjectNegotiableMOQ: 10 Square Meters -
Pneumatic Shield Gate Shield-type Rubber Dam Air Shield Dam Spillway Gate Inflatable Rubber Dam Sold to Thailand, Malaysia, PhilippinesUS$ 1200 - 1500MOQ: 10 Square Meters
-
Air Shield Dam | Inflatable Rubber Dam With Steel Facing for Landscape and Flood ManagementUS$ 1200 - 1500MOQ: 10 Square Meters
-
ISO9001 Heavy Duty Shield Rubber Dam 20 Years Lifespan for Water ProjectUS$ 1200 - 1500MOQ: 10 Square Meters
-
Hydraulic Engineering Rubber Dam Air Shield Dam for RiverUS$ 1200 - 1500MOQ: 10 Square Meters
The Inflatable Air-Shield Dam with PTFE coating provides instant flood protection for construction sites and equipment yards. This innovative barrier deploys within minutes using air inflation technology, creating a reliable seal against water intrusion. Engineered for industrial applications, our flexible dam solution minimizes downtime during unexpected weather events while offering reusable performance across multiple projects.
Manufactured by Hengshui Haogu Engineering Materials, this Chinese-engineered product meets international quality standards with ISO and QS certifications. The dam's unique PTFE-coated fabric construction delivers superior chemical resistance and durability in harsh environments, outperforming traditional sandbag barriers in both setup speed and long-term cost efficiency.
Key operational advantages include:
⛔ Rapid deployment – operational in under 10 minutes with standard air pumps
♻️ Reusable design – compact storage footprint when deflated
⚡ Adaptive sealing – conforms to uneven terrain surfaces
🌊 Multi-scenario protection – effective for floods, spills, and equipment isolation
| Parameter | Specification | Performance Benefit |
|---|---|---|
| Material Composition | Reinforced polymer + PTFE coating | Resists UV degradation & chemical corrosion |
| Height Range | Customizable 30-120cm | Adapts to variable flood depths |
| Connection System | Interlocking air chambers | Creates continuous barrier lines |
| Inflation Pressure | 0.2-0.35 bar (adjustable) | Maintains structural integrity |
Installation Process Simplified: Our three-step deployment system requires minimal training. First, unroll the dam along the protection perimeter. Second, connect standard air compressor fittings (compatible with most industrial compressors). Third, inflate to recommended pressure levels indicated on the integrated gauge ports. The dam's weighted base automatically creates a ground seal while the air tube expands vertically.
💡 Maintenance Tip: After water exposure, rinse with fresh water and air-dry before storage. Properly maintained units provide 50+ deployment cycles without performance degradation.
Global Project Compatibility: With shipments available from Tianjin, Qingdao, Ningbo, and Shanghai ports, our dams have protected infrastructure projects across six continents. The modular design allows configuration for:
Tunnel entry flood prevention
Construction pit isolation
Equipment yard perimeter security
Temporary spill containment
Historical site preservation
Basement flood defense systems
For specialized applications, our engineering team offers custom solutions including extended lengths, reinforced anchoring systems, and integration with remote monitoring equipment.
Frequently Asked Questions
Q: What's the maximum water depth this dam can contain?
A: Standard models contain up to 1.2 meters of standing water. Custom heights available upon request.
Q: How does the PTFE coating enhance performance?
A: PTFE (Polytetrafluoroethylene) creates a non-stick surface that prevents debris accumulation and simplifies cleaning.
Q: Can multiple dam units connect for longer barriers?
A: Yes, interlocking connectors create continuous barriers up to 500 meters without leakage points.
Q: What air pressure monitoring is included?
A: Each 5-meter section has two gauge ports for real-time pressure checks during operation.
Q: How does this compare to traditional sandbag barriers?
A: Our dam deploys 8x faster, requires 90% less storage space, and eliminates manual labor costs.
⚠️ Important Notice: Always conduct a site assessment before deployment. Steep gradients (over 15°) or fast-moving water currents may require supplemental anchoring systems. Contact our technical team for site-specific recommendations.
Ready to Enhance Your Site Protection?
Request project-specific quotations including volume discounts and expedited shipping options from our Chinese manufacturing facility. Our engineering support team provides complimentary deployment planning for orders exceeding 100 linear meters.
📞 Contact our flood protection specialists today for technical datasheets and regional case studies demonstrating successful installations in North American construction sites and Southeast Asian infrastructure projects.
