Zalip 4g Dual-sim Dual-mode Industrial Router With Dual Sim Card Standby, Load Balancing, and Bandwidth Aggregation, Gps Positioning, Support for Rs232/rs485 Dtu Serial Communication, Gpio, and Poe

The above quotation is for the dual-module, dual-SIM, dual-standby version. Additionally, there are single-module, dual-SIM versions, 5-LAN-port, dual-module, dual-SIM, dual-standby versions, Gigabit editions, and international editions available for customization. You can consult the customer service according to your needs.

○ Bandwidth aggregation


Supports the aggregation of the network bandwidth of two SIM cards, doubling the transmission bandwidth and significantly improving the upload and download speeds. For large data such as videos and pictures,


long-distance transmission is smoother and clearer.




○ Intelligent link switching and backup
Provides various forms of communication link backup functions: It has three backup paths including two wireless and one wired path, with a total of three backup paths, one primary and two secondary backup,


dual-link equal backup and other backup forms.




○ Reliable networking and communication
Adopts high-performance industrial-grade wireless modules and industrial-grade high-stability, high-precision components. It has an extremely wide temperature design from -25 to +75°C, easily adapting to


high-temperature and cold working environments, and providing reliable networking and stable channels for unattended systems.



   ● Optionally supports 4G (FDD LTE), EVDO, WCDMA, and is backward compatible with HSUPA/EVDO/GPRS. It also supports the full-network mode with multiple modes in one device.
● Supports DNS proxy and DDNS.

The dual-module, dual-SIM design enables wired/wireless mutual backup.

The device is designed with dual modules and dual SIM cards. The two modules back up each other and automatically select the optimal network for transmission.

It supports wired and wireless access to the Internet, with wired/wireless dual backup.

Supports APN/VPDN private network access, protecting the financial industry.

Supports the APN/VPDN of the operator's private network and supports the access to virtual private networks through various protocols such as IPSec, PPTP, L2TP, and GRE.

Industry applications

The two SIM cards of 4G are online simultaneously for bandwidth aggregation. The transmission bandwidth is doubled.

Powerful cloud platform for remote management.

Industrial-grade application design

• Adopt high-performance industrial-grade wireless modules

• Adopt high-performance industrial-grade 32-bit communication processors

• Adopt dual-card design to ensure the stability and reliability of the device

• Support low-power modes, including sleep mode, timed online/offline mode, and timed power-on/off mode (only supported in special versions)

• Adopt a metal shell with a protection level of IP30. The metal shell is safely isolated from the system, which is particularly suitable for applications in industrial control sites

• Wide power input (DC 5~36V)

Standard and easy to use

• Provide standard RS232 (or RS485/RS422), Ethernet, and WIFI interfaces, which can be directly connected to serial devices,
  Ethernet devices, and WIFI devices

• Provide a standard wired WAN port (supporting the standard PPPOE protocol), which can be directly connected to ADSL devices

• Intelligent data terminal that can enter the data transmission state once powered on

• Provide powerful central management software for convenient device management (optional)

• Easy and flexible to use, with multiple working mode options

• Convenient system configuration and maintenance interfaces (including local and remote WEB or CLI methods)

•


Powerful functions

• Support the intelligent switching function of dual links between the primary card and the backup card

• Support multiple WAN connection methods, including static IP, DHCP, L2TP, PPTP, PPPOE, 2G/3G/4G

• Support the intelligent switching and backup function of dual links between wireless cellular and wired WAN (optional)

• Support local and remote online upgrades, import and export of configuration files

• Support NTP and have a built-in RTC

• Support multiple domestic and international DDNS

• Support VLAN, MAC address cloning, and PPPoE server

• WIFI supports 802.11b/g/n, and supports multiple working modes such as WIFI AP, AP Client, repeater,
  repeater bridge, and WDS (optional)

• WIFI supports multiple encryption methods such as WEP, WPA, WPA2, and supports functions such as RADIUS authentication,
  MAC address filtering

• Support multiple online/offline triggering modes, including SMS, phone ringing, serial data, and network data triggering online/offline modes

• Support complete network protocols such as TCP/IP, UDP, TELNET, FTP, HTTP

• Timed power-on/off and timed online/off functions

Security deployment scheme, data transmission meets financial-level standards

• Supports VPN client (PPTP, L2TP, IPSEC, OPENVPN, and GRE) (Note: Only supported in the VPN version)

• Supports VPN server (PPTP, L2TP, IPSEC, OPENVPN, and GRE) (Note: Only supported in the VPN version)

• Supports remote management, functions such as SYSLOG, SNMP, TELNET, SSHD, and HTTPS

• Supports functions such as SPI firewall, VPN traversal, access control, and URL filtering

• Supports APN/VPDN

• Supports multiple DHCP servers and DHCP clients, DHCP MAC address binding, DDNS, firewall, NAT, DMZ host,

• QoS, traffic statistics, real-time display of data transmission rate and other functions

• Supports functions such as DHCP server and DHCP client, DDNS, firewall, NAT, and DMZ host
