HST MRS-10 Four Ball Wear Testing Machine Computer-Controlled Electronic-Hydraulic Power Steel Material Abrasion Testing 1-Year

HST MRS-10 Four Ball Wear Testing Machine Computer-Controlled Electronic-Hydraulic Power Steel Material Abrasion Testing 1-Year thumbnail-1
HST MRS-10 Four Ball Wear Testing Machine Computer-Controlled Electronic-Hydraulic Power Steel Material Abrasion Testing 1-Year thumbnail-2
HST MRS-10 Four Ball Wear Testing Machine Computer-Controlled Electronic-Hydraulic Power Steel Material Abrasion Testing 1-Year thumbnail-3
HST MRS-10 Four Ball Wear Testing Machine Computer-Controlled Electronic-Hydraulic Power Steel Material Abrasion Testing 1-Year thumbnail-4
HST MRS-10 Four Ball Wear Testing Machine Computer-Controlled Electronic-Hydraulic Power Steel Material Abrasion Testing 1-Year thumbnail-5
HST MRS-10 Four Ball Wear Testing Machine Computer-Controlled Electronic-Hydraulic Power Steel Material Abrasion Testing 1-Year thumbnail-6
HST MRS-10 Four Ball Wear Testing Machine Computer-Controlled Electronic-Hydraulic Power Steel Material Abrasion Testing 1-Year photo-1
HST MRS-10 Four Ball Wear Testing Machine Computer-Controlled Electronic-Hydraulic Power Steel Material Abrasion Testing 1-Year photo-2
HST MRS-10 Four Ball Wear Testing Machine Computer-Controlled Electronic-Hydraulic Power Steel Material Abrasion Testing 1-Year photo-3
HST MRS-10 Four Ball Wear Testing Machine Computer-Controlled Electronic-Hydraulic Power Steel Material Abrasion Testing 1-Year photo-4
HST MRS-10 Four Ball Wear Testing Machine Computer-Controlled Electronic-Hydraulic Power Steel Material Abrasion Testing 1-Year photo-5
HST MRS-10 Four Ball Wear Testing Machine Computer-Controlled Electronic-Hydraulic Power Steel Material Abrasion Testing 1-Year photo-6
US$ 2000 - 8000 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Testing Machine
brand name:
hensgrand
place of origin:
Shandong, China
Contact Supplier Request Quote Chat Now
Hst Group Co.,ltd.
Gold Verified Supplier
1Yr
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
brand name hensgrand
place of origin Shandong, China
customized support OEM, ODM, OBM
power 750
Voltage 220 V, 380 V, 240 V, 110 V, 415 V
warranty 1 Year
model number MRS-10A
Product name four ball wear testing machine MRS-10
Relative error of load ±1%
Load range 10~1000N(stepless)
Certificate CE ISO
Model MRS-10A
Port Qingdao
MOQ 1 set
Origin China
Delivery time 7-15 Working days
Brand HST

four ball wear testing machine MRS-10

MRS-10A Computer Control Servo Four Ball Friction Testing MachineHST MRS-10 Four Ball Wear Testing Machine Computer-Controlled Electronic-Hydraulic Power Steel Material Abrasion Testing 1-YearHST MRS-10 Four Ball Wear Testing Machine Computer-Controlled Electronic-Hydraulic Power Steel Material Abrasion Testing 1-YearHST MRS-10 Four Ball Wear Testing Machine Computer-Controlled Electronic-Hydraulic Power Steel Material Abrasion Testing 1-Year



Application:

The machine can simulate rolling, sliding and rolling & sliding combined movement under the certain contact pressure to complete point, line and plane simulating tests. It can be used to evaluate the friction and wear performance of lubricant, metal, plastics, coating, rubber, ceramics etc. It can not only content with the needs of traditional petrochemical industry to research, develop and inspect the various kinds of intermediate & high grade hydraulic oil, combustion engine oil and gear oil. Also it can be tested under dry condition, but also the needs of simulating evaluation to new material development and new technology research.



Features:

The machine adopts process control principle, and combines industrial control computer with the configuration software technology and internet technology; Apply incorporate structure design, integrate embedded industry computer, configuration software, acquisition module and executor as a whole to control the test process, all test operation can be completed at the main interface of the computer; It features flexible configuration control mode, multiple friction couplings, wide speed adjusting range, simulating high temperature circumstances, high automation and easy to use.



Specifications

Load range

10~1000N(stepless)

Relative error   of load indicating value

±1%

Friction   torque measuring range

2.5N.m

Relative error   of friction torque indicating value

±2%

Rotate speed   range of spindle

1~2000r/min, linear   velocity up to over 4 m/s.

Test medium

oil, water, slurry,   abrasive etc.

Temperature   control range

Room   temperature~300°C

Max. Distance   between spindle of the machine and lower friction coupling pate

>75mm





HST MRS-10 Four Ball Wear Testing Machine Computer-Controlled Electronic-Hydraulic Power Steel Material Abrasion Testing 1-YearHST MRS-10 Four Ball Wear Testing Machine Computer-Controlled Electronic-Hydraulic Power Steel Material Abrasion Testing 1-Year
