China Waw600D Steel Bar Bending Testing Machine 1000kn Max Load ASTM Standard 220V Voltage for Compression Measurement 1 Year
1. Application
Factory Steel Rebar Steel Strip Steel Sheet Tensile Test Equipment for sale is suitable for tension,
compression, bending, shearing, peeling, tearing and other tests by adding different test fixture for metal and nonmetal materials. It is widely used in inspection department, engineering area, laboratories, universities and institutes for material properties research and quality control.
2. Standards
ISO75001, ASTM A370, ASTM E4, ASTM E8 and BSEN standards
3.Specification:
|
Product Model |
HST WAW-600E |
|
Number of columns |
6 (4 columns and 2 screws) |
|
Load Capacity |
600kN |
|
Load Capacity |
60000kgf |
|
Calibration standard |
ISO 7500 |
|
Calibration standard |
Class 0.5 |
|
Testing load Accuracy |
±0.5% |
|
Load Measuring Range |
1%~100%FS |
|
Load Resolution |
1/500,000 of FS |
|
Accuracy of Stress Rate Control |
±0.5% |
|
Displacement resolution |
0.0025mm |
|
Main frame parameters |
|
|
Max. Tensile Testing Space |
950mm |
|
Max. Compression Testing Space |
700mm |
|
Distance between two columns |
560mm |
|
Column diameter |
Φ72mm |
|
Max. Piston stroke |
250mm |
|
Piston diameter |
Φ230mm |
|
Testing Speeds |
|
|
Cross beam adjustment for max speed |
About 220 mm/min |
|
Cross beam moving motor power |
0.4KW |
|
Control mode |
Force closed loop control, deformation closed loop control, displacement closed loop control |
|
Force control controls the speed range |
0.001%~5%FS/s |
|
Force control speed control accuracy |
When 0.001% ~ 1% FS/s is better than ≤± 0.5%; When 1% ~ 5% FS/s better than ≤± 0.2% |
|
±0.002%F.S |
|
|
Clamping mode |
Built-in wedge type hydraulic automatic clamping |
|
Overall dimensions of the jaws |
90x90mm |
|
Round specimen clamping range |
Φ13-26, Φ26-40mm,Optional:Φ6-13mm; |
|
Flat specimen clamping thickness |
0-20mm;Optional:20-40mm |
|
Compression plate dimensions |
Φ160mm |
Send Inquiry to This Supplier
