| MODEL | WDW-01E | WDW-10E | WDW-20E | WDW-50E | WDW-100E | WDW-1000E |
| Load Capacity (kN) | 0.1 | 10 | 20 | 50 | 100 | 1000 |
| Calibration Standard | Class 0.5 to ISO7500 - 1, ASTM E4 | |||||
| Load Accuracy | Class 0.5 | |||||
| Load Range | 0.2% ~ 100%F.S | |||||
| Resolution Of Displacement (μm) | 0.04 | |||||
| Test Speed (mm/min) | 0.001-500/0.001-1000/0.05-500 Depending on diffrent model | |||||
| Test Speed Accuracy | Within +/- 0.5% of the value | |||||
| Tensile Space (mm) | 800/1000 (heighten model) | 650/770/800Depending on diffrent model | ||||
| Crosshead Travel Space (mm) | 800/1000 (heighten model) | 1100/900 Depending on diffrent model | ||||
| Gross Weight (KG) | 110/150 (Packing weight) | 420/680/1800/4000 Depending on diffrent model | ||||
| Dimension (mm) | 520*400*1340/630*500*1480 (Packing size | 850*550*1824 etc./The larger the model, the greater its size. | ||||
| Power Supply | AC220V+-10%,50Hz/60Hz/AC380V+-10%,50Hz/60Hz(can be customized) | |||||
|
TIP:Extra wide/height frames is avaiable. Didn't find the model you need? For more information on other models, feel free to contact us. |
||||||
Q1: What is your warranty?
A: The testing machine is guaranteed for 16 months by HST,we can help youto repair your problem controller freely,even it's not from our factory. Free Non-consumable components will be provided if any performance failure occurs within 16 months caused by non-human damage.
Q2: How to vedio provided?
A: Yes. if required, our engineers will record a specialize how-to video for you.
Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory&trade company (integration).15+ years focusing on test instruments field. 6 years exporting experience, warmly welcome to visit our plant (factory), we also support OEM and ODM service.
Q4: After an order is placed, when to deliver?
A: Generally about 10-25days, If we have inventory, we can arrange shipmentwithin 3 days.Please be aware that our production lead times depend on specificitems and item quantities.
Q5: What about the after-sales service and product’s quality?
A:Each instruments must be carried out 100% quality examination and test whenshipping and delivery goods. Engineers would be go abroad to training, repair and others help you need.
Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the stanard exporting wooden case, which not only has good shock absorption, impact resistance, heat sso has the advantag- es of nontoxic, odorless, moisture corrosion, good transparency etc.
