Help CenterDual Core Mineral Insulated Heating Cable for Pipe Freeze Protection and Roof De-icing
Related Products
-
Pre-Terminated MI Heating Cable With Waterproof End Seals for Outdoor UseNegotiableMOQ: 500 Meters -
Flexible Mineral Insulated Heating Cable Dual Core Compatible With Most Temperature ControllersNegotiableMOQ: 500 Meters
-
MI Heating Cable Double Sheath Mineral Insulation for Industrial Process Heating SystemsNegotiableMOQ: 500 Meters
-
Mineral Insulated Trace Heating Cable With Fiberglass Overbraid 450°C RatingNegotiableMOQ: 500 Meters
-
Stainless Steel Sheathed MI Cable for High-Temperature Process HeatingNegotiableMOQ: 500 Meters
Shandong Huaning Electric Heating Technology Co., Ltd, based in Jinan, Shandong, China, specializes in high-quality heating solutions. Our Dual Core Mineral Insulated Heating Cable is designed for reliable pipe freeze protection and roof de-icing applications. With superior durability and performance, this cable ensures safety and efficiency in harsh environments. Trust our expertise to deliver heating solutions that meet your specific needs.
Key Features:
Dual Core Design: Provides consistent and efficient heat distribution.
Mineral Insulation: Magnesium oxide insulation ensures high thermal conductivity and durability.
Wide Temperature Range: Operates effectively from -60°C to 250°C.
Flexible Sheath Options: Available in copper or stainless steel for varied applications.
Customizable Lengths: Tailored to fit your specific project requirements.
Technical Specifications:
Rated Voltage |
Outer Diameter of Sheath (mm) |
Maximum Operating Length (m) |
Dielectric Strength |
Maximum Powerper Meter (W/m) |
AC220V Double-core |
6 |
10 |
120DVAc/imin |
300 |
5.5 |
30 |
1200VAc/imin |
150 |
|
5.2 |
40 |
1200Vac/imin |
100 |
|
5 |
60 |
1200VAC/imin |
50 |
|
4.6 |
120 |
1200VAc/imin |
20 |
Why Choose Our Heating Cable?
Reliable Performance: Ensures continuous operation in extreme conditions.
Energy Efficient: Minimizes heat loss, reducing operational costs.
Easy Installation: Flexible design allows for straightforward setup.
Long Lifespan: Built to last with high-quality materials.
Trust and Quality Assurance
As a leading manufacturer in Jinan, Shandong, we are committed to delivering top-tier heating solutions. Our Dual Core Mineral Insulated Heating Cable is a testament to our dedication to quality and innovation. Whether for industrial or residential use, our products are designed to meet the highest standards. Contact us today to discuss your requirements and discover how our solutions can benefit your projects.
FAQ:
Q: What is the maximum temperature this cable can withstand?
A: The cable operates effectively up to 250°C.Q: Can the cable be used for both pipe freeze protection and roof de-icing?
A: Yes, it is designed for both applications.Q: What sheath materials are available?
A: Copper and stainless steel options are available.Q: Is the cable customizable in length?
A: Yes, we offer various lengths to suit your needs.Q: What is the voltage rating?
A: The cable is rated for 120V/240V.Q: How durable is the cable in harsh environments?
A: The mineral insulation and robust sheath ensure long-term durability.
