MS35 Series Hydraulic Motor
1.radial piston design.
2.higher output torques,lower output speed,smoother output speed at low speeds.
3.optimized and modular design capable of delivering high performance.
4.highly efficient at any speed or operating pressure.
5.withstand the most extreme operating conditions and require very little maintenance.
**IMPORTANT INFORMATION**
As with any hydraulic system, proper flushing of the system is crucial to the system performing at its maximum efficiency. Before installation, make sure all lines, filters, and reservoirs are flushed, cleaned and properly inspected or replaced before installing knew hydraulic pump, motor or transmission.
|
Displacement Group |
7 | 9 | 0 | 2 |
|
Displacement(ml/r) |
2439 | 3143 | 3494 | 4198 |
| Theoretical torque a 10Mpa(N.m) | 3878 | 4997 | 5555 | 6675 |
|
Rated speed(r/min) |
100 | 100 | 100 | 100 |
|
Rated pressure(Mpa) |
25 | 25 | 25 | 25 |
|
Rate torque(N.m) |
8000 | 10300 | 11450 | 13800 |
|
Max pressure(Mpa) |
31.5 | 31.5 | 31.5 | 31.5 |
|
Max torque(N.m) |
9850 | 12700 | 14150 | 17000 |
|
Speed range(r/min) |
0-140 | 0-140 | 0-130 | 0-130 |
| Max power(kW) | standard displacement is 110kw,variable displacement priority rotation 73kw,no priority is 55kw. | |||
Our advantages
1).High performance:our motor performance is very close to Poclain original motors, even sometimes be superior to original motor.
2).100% interchangeable:both complete motor and spare parts, our products could completely replace to Poclain original motors.
3).Reasonable price:our price system has been settled much lower than Poclain original motors.
4).Fast delivery time:most of the spare parts we have inventory, the delivery time keeps within 10 days for regular motor.
5).Excellent aftersales service:we have 12 months' quality warranty, and within warranty time ,all repairment are free of charge
