T1000 E/P BELLOFRAM Transducer

Bellofram Silicones, Inc. is honored to provide customers with design, production, and distribution services for specialty rubber products, as well as a range of supporting instrumentation product lines. Their materials are designed to achieve high performance and long lifespan in applications that are sensitive to extreme temperatures and compression induced permanent deformation. They provide solid silicone with various hardness levels and sponges with hardness ranges, making them the preferred materials for aerospace, transportation, food service, lighting, and industrial fields.

1. Product Description of BELLOFRAM Sensor 1000 T1000 E/P in the United States

① The 1000 type sensor is an electric pneumatic device that can reduce the supply pressure to a regulated output pressure proportional to the electrical input signal.

② The acceptable gas supply pressure range for the 1000 model is very wide, ranging from a minimum value of 3 PSI (0.2 BAR) above the maximum output pressure to a maximum value of 100 PSIG (6.9 BAR).

③ This design includes a built-in pneumatic supercharger that can provide high flow rates (up to 12 SCFM/339 SLPM).

④ The optional models include universal, NEMA 4X, expansion, high overflow, intrinsic safety, and explosion-proof.

2. BELLOFRAM Sensor 1000 T1000 E/P Product Features:

① Lightweight and cost-effective

② Built in volume enhancer

③ Small size

④ On site reversible

⑤ Low air consumption

⑥ Installation at any angle

⑦ Convenient external range and zero adjustment (excluding explosion-proof models)

⑧ Wide supply pressure range

⑨ Low supply pressure sensitivity

3. Application of BELLOFRAM Sensor 1000 T1000 E/P Product in the United States:

① Valve actuator

② Wind door and louver actuators

③ Valve positioner

④ Controller

⑤ Relay

⑥ Cylinder

⑦ Clutch and brake

⑧ Liquid, gas, and slurry processing instruments

⑨ HVAC system

⑩ Paper processing control

⑪ Textile processing system

⑫ Energy Management System

⑬ Petrochemical processing system

⑭ Segmented distance measurement

4. BELLOFRAM Sensor 1000 T1000 E/P Product Overview from the United States

① The 1000 type sensor is an electric pneumatic device that can reduce the supply pressure to a regulated output pressure proportional to the electrical input signal.

② The acceptable gas supply pressure range for the 1000 model is very wide, ranging from a minimum value of 3 PSI (0.2 BAR) above the maximum output pressure to a maximum value of 100 PSIG (6.9 BAR).

③ This design includes a built-in pneumatic supercharger that can provide high flow rates (up to 12 SCFM/339 SLPM). The optional models include universal, NEMA 4X, expansion, high overflow, intrinsic safety, and explosion-proof.

5. BELLOFRAM Sensor 1000 T1000 E/P Product Details

① The typical value is ± 0.1% of the full-scale output (with a guaranteed value of 0.25%); Including the effects of lag, dead zone, and repeatability

② Patented sealed piezoelectric ceramic dual chip and isolated electronic devices

③ Available pressure up to 120 PSIG (zero basis)

④ Highly resistant to electromagnetic interference/radio frequency interference

⑤ Not sensitive to extreme temperature and supply pressure fluctuations

⑥ Not sensitive to extreme vibrations and directions

⑦ Explosion proof and dust-proof versions (EX model)
